USE AND CARE GUIDE
RILEY 44-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
To view an instructional video on how to install this product:
1. Go to www.homedepot.com and enter either the Item or Model number, found in the top
right corner of the cover of this instruction manual, in the search eld.
2. Click on your product from the list of search results and click on the video link in the
"Product Overview" section.
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Related Manuals for HAMPTON BAY 1005 819 968
Summary of Contents for HAMPTON BAY 1005 819 968
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................14 Warranty ................3 Care and Cleaning ............. 15 Pre-Installation ..............3 Troubleshooting ..............15 Installation ................6 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as To reduce the risk of electric shock, ensure the electricity has been... -
Page 3: Warranty
A certain amount of “wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Hampton Bay hereby disclaims any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by law. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Extension leadwire Plastic wire connector Hanger pin Locking pin Wall mount screws Wall anchor...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket Blade (inside canopy) Blade arm Canopy LED bulb Canopy bottom cover Remote control (battery included) Ball/downrod assembly Receiver Fan-motor assembly Wall bracket Light kit fitter assembly Battery Glass shade IMPORTANT: This product and/or components are governed by one or more of the following U.S.
-
Page 6: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock, proper blade clearance when installing on a steep, sloped or personal injury, mount the fan to an outlet box ceiling. -
Page 7: Assembly
Assembly - Standard Ceiling Mount Preparation for standard mounting Routing the wires □ □ Remove the canopy bottom cover (C) from the canopy (B) by Route the wires exiting the top of the fan motor assembly (E) turning the bottom cover counterclockwise until it unlocks. through the center of the canopy bottom cover (C). - Page 8 Assembly - Hanging the Fan Attaching the fan to the electrical Hanging the fan WARNING: To reduce the risk of fire, electric shock, or other WARNING: When using the standard ball/downrod mounting, personal injury, mount the fan to an outlet box marked the tab in the ring at the bottom of the mounting bracket “Acceptable for fan support of 35 lbs (15.9 kg) or less”...
- Page 9 Assembly - Hanging the Fan (continued) Wiring the receiver to the household Installing the receiver wiring WARNING: To reduce the risk of fire or electric shock, WARNING: To avoid possible electrical shock, turn the remember to disconnect power. The electrical wiring must electricity off at the main fuse box before wiring.
- Page 10 Assembly - Hanging the Fan (continued) Wiring the fan to the receiver Attaching the canopy □ Align the locking slots of the canopy (B) with the two screws NOTE: The fan comes with 12 in. lead wires for use with the (PP) and alignment post (EE) in the mounting bracket (A).
- Page 11 Assembly - Attaching the Blades Attaching the blade bracket Attaching the fan blades NOTE: This fan features Quick Install blades for fast and easy □ Fasten the blade bracket (I) to the motor (E) by inserting the blade installation. alignment post into the slot on the bottom of the fan-motor □...
- Page 12 Assembly - Attaching the Light Kit Attaching the light kit Installing the glass bowl CAUTION: Make sure the power is off before attaching CAUTION: To reduce the risk of electric shock, disconnect or removing the glass bowl. the electrical supply circuit to the fan before installing. □...
- Page 13 Preparing the Remote Control Pairing the Remote Control WARNING: a) The cells shall be disposed of properly, including keeping them away from children; b) even used cells may cause injury. NOTE: The remote control has already been paired to the ceiling fan for your convenience.
-
Page 14: Operation
Operating Your Fan Your fan is equipped with a remote control to operate the fan speed A. Warm weather and lights of your new ceiling fan. The appropriate speed settings for warm or cool weather depends on factors such as the room size, ceiling height, and number of fans. The fan is shipped from the factory with the reversing switch positioned to circulate air downward. -
Page 15: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □... - Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
