Dimensions
ISE70 75 75H
Lead wire with M12
connector (5m)
straight
(28.7)
(38.2)
With bracket
(28.7)
(38.2)
Digital Pressure Switch
For Air/For General Fluids
9 39
15.7
Lead wire with M12
connector (5m)
right-angled
9 44.5
35
ISE70/75/75H
Series
24
Piping port
02: Rc1/4
N02: NPT1/4
F02: G1/4 (ISO1179)
34
MPa
OUT1
U P DOWN
SET
24
Piping port
02: Rc1/4
N02: NPT1/4
F02: G1/4 (ISO1179)
34
MPa
OUT1
U P DOWN
SET
46
60
Note) The connector faces down
(toward the piping). Do
not attempt to rotate the
connector, as it is not
rotatable.
2
1
3
4
Connector Pin
Assignments
Output -43
1 Brown DC (+)
2 White OUT1 (PNP)
3 Blue DC (–)
4 Black OUT1 (NPN)
Output -65
1 Brown DC (+)
2 White NC
3 Blue DC (–)
4 Black OUT1 (PNP)
