SMC Networks ISE70 Series Manual page 12

Series
Specific Product Precautions 2
Be sure to read before handling. Refer to pages 7 through 9 for safety instructions and pressure
switch precautions.
Caution
1.
Set the pressure within the rated pressure range.
The set pressure range is the range of pressure that is possible in setting.
The rated pressure range is the range of pressure that satisfies the specifications (accuracy, linearity, etc.) on the sensor.
Although it is possible to set a value outside the rated pressure range, the specifications will not be guaranteed even if the value stays
within the set pressure range.
Switch
For 1MPa
ISE70
–100kPa
(For Air)
(–0.1MPa)
For 10MPa
ISE75
(For General Fluids)
For 15MPa
ISE75H
(For General Fluids)
The ISE75/75H switch shows zero (0) when the pressure being applied goes below the lower limit of the set pressure range.
