Quick start:
Trocal LED Control & GHL Control Center

1. How to connect the Trocal LED control

Connect the power adapter of a "Trocal LED" with the LED Control by means of the cable "LED Connect"
and connect it to a power outlet. You can now establish a connection to the PC via the included USB
cable.
Note: The DENNERLE Trocal LED control can only be programmed with the PC software "GHL Control
Center (GCC)" if the device has at first been connected to the PC via the USB connector and before
opening the application.
1.1 Now open the GHL Control Center
1.2 When first opening the GCC, the following error
message appears: "Connection failed. Would
you like to check settings now?" Choose "Yes" in
the Popup
1.3 In order to connect the DENNERLE Trocal LED
Control automatically with the GCC after
program start, please activate the check box in
the line "Dennerle Trocal LED control" and
"Establish standard connection automatically
after program start"
Confirm with "Close":
1.4 You can now connect the DENNERLE Trocal LED
Control with the software by double-clicking on it
in the side bar.
Please note: These steps are only necessary the first time you are establishing a connection. The next
time the program is started, the connection between the DENNERLE Trocal LED Control and GHL Control
Center will be established automatically.
