HDMI OVER IP EXTENDER
PANEL DESCRIPTION
HDMI EXTENDER TX (Sender)
Power input (DC5V)
HDMI signal input
RJ45 signal output
Reset
HDMI EXTENDER RX (Receiver)
Power input (DC5V)
HDMI signal output
RJ45 signal input
Reset
INSTALLATION PROCEDURES
1. How to make a Cat.5/6 network cable
Follow the standard EIA-568B:
1 - Orange/white
2 - Orange
3 - Green/white
4 - Blue
5 - Blue/white
6 - Green
7 - Brown/white
8 - Brown
