Operating Instructions
MAVO-SPOT
With Measuring Angle 1 Degree
For Measuring Luminance from the Distance
Attachment for MAVO-MONITOR
Lens with protective
filter or close-up lens
and stray light shield
Battery compartment
2
MAVO-SPOT
Index
1
Applications...........................................
2
2.1
Inserting The Battery................................
2.2
Battery Check.........................................
3
Using The Mavo-Spot........................
3.1
Preparations...........................................
3.2
Measuring...............................................
4
Accessories ...........................................
4.1
Standard Equipment................................
4.2
Optional Accessories...............................
4.3
Calibration Certificate..............................
5
Servicing And Repairs..........................
6
Technical Data.......................................
Declaration Of Conformity....................
Warning: Do not aim the MAVO-SPOT at the sun. You would risk damaging your eye and also the light sensor
may be destroyed!!
GOSSEN Foto- und Lichtmesstechnik GmbH
Eye-piece with
eye-cup
On/Off switch
Battery check
Connection cable
Page
2
2
2
2
2
2
2
2
2
3
3
3
3
4
15167
1/7-04
