Loop Armoire
Designed by Earnest Studio for Design Within Reach
Customer Service:
1.800.944.2233 inside the U.S.
1.203.614.0600 outside the U.S.
1 | W W W. D W R . C O M | 1. 8 0 0 . 9 4 4 . 2 2 3 3 | D E S I G N W I T H I N R E A C H S T U D I O S
HARDWARE CHECKLIST
Shelf pins x 12
(Included with
the Armoire with
Shelves only)
SAFETY STRAP KIT
Short screw x 2
Bracket x 2
TOOLS (NOT INCLUDED)
Phillips screwdriver
Long screw x 2
Safety strap x 1
For care instructions, please visit
dwr.com/learn.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Design Within Reach Loop Armoire 100172204
Summary of Contents for Design Within Reach Loop Armoire 100172204
- Page 1 Loop Armoire Designed by Earnest Studio for Design Within Reach HARDWARE CHECKLIST TOOLS (NOT INCLUDED) Shelf pins x 12 (Included with Phillips screwdriver the Armoire with Shelves only) SAFETY STRAP KIT Short screw x 2 Long screw x 2 Bracket x 2...
- Page 2 Loop Armoire Cabinet is packed with sheet of MDF attached to base with leveling feet. To remove, lay cabinet on back and remove leveling feet by turning counterclockwise. After removing MDF sheet, return leveling feet to legs. With armoire in final location, check for level from side to side and front to back. Adjust leveling feet, as shown, until cabinet is level in all directions. LOWER RAISE 2 | W W W.
- Page 3 Loop Armoire Door and drawer pulls are factory installed facing inward for shipping. Remove each with a screwdriver, then reinstall facing outward. 3 | W W W. D W R . C O M | 1. 8 0 0 . 9 4 4 . 2 2 3 3 | D E S I G N W I T H I N R E A C H S T U D I O S...
- Page 4 Loop Armoire If you chose the Armoire with Shelves, remove coatrack bar and save for potential future use. Metal pins holding coatrack bar are not designed to be removed. Install four shelf pins for each shelf at positions that will best serve your needs, making sure all pins for a single shelf are installed at the same level.
- Page 5 Loop Armoire Once shelf pins have been installed, tilt shelf slightly to fit into case, then lower onto shelf pins. 5 | W W W. D W R . C O M | 1. 8 0 0 . 9 4 4 . 2 2 3 3 | D E S I G N W I T H I N R E A C H S T U D I O S...
- Page 6 Loop Armoire Shelves installed. 6 | W W W. D W R . C O M | 1. 8 0 0 . 9 4 4 . 2 2 3 3 | D E S I G N W I T H I N R E A C H S T U D I O S...
- Page 7 Loop Armoire Safety strap kit, included with your Loop Armoire, must be installed. Follow instructions with kit. Wall Safety strap kit 7 | W W W. D W R . C O M | 1. 8 0 0 . 9 4 4 . 2 2 3 3 | D E S I G N W I T H I N R E A C H S T U D I O S...
- Page 8 Loop Armoire To raise or lower drawer, locate knobs next to latch pins on each slide underneath the drawer. Turn knobs to adjust height of drawer. 8 | W W W. D W R . C O M | 1. 8 0 0 . 9 4 4 . 2 2 3 3 | D E S I G N W I T H I N R E A C H S T U D I O S...
- Page 9 Loop Armoire NOTE: To remove drawer, pull all the way out. Reach under drawer and locate downward protruding latch pins on drawer slides, one on each side, as shown below. Push both pins inward toward center of drawer to release drawer from slide. Drawer can now be lifted off slides. Reverse process to reinstall. Door Adjustments LEFT/RIGHT ADJUSTMENT UP/DOWN ADJUSTMENT...
