VHD3200D
User Guide
The Future of Sound.
Made Perfectly Clear.
At KV2 Audio our vision is to constantly develop technologies
that eliminate distortion and loss of information providing
a true dynamic representation of the source.
Our aim is to create audio products that absorb you,
place you within the performance and deliver a listening
experience beyond expectations.
Advertisement
Table of Contents
Related Manuals for KV2 Audio VHD3200D
Summary of Contents for KV2 Audio VHD3200D
- Page 1 User Guide The Future of Sound. Made Perfectly Clear. At KV2 Audio our vision is to constantly develop technologies that eliminate distortion and loss of information providing a true dynamic representation of the source. Our aim is to create audio products that absorb you, place you within the performance and deliver a listening experience beyond expectations.
- Page 3 VHD3200D · Important Safety Instructions Important Safety Instructions Before using your VHD3200D Amplifier, be sure to carefully read the applicable items of these operating instructions and the safety suggestions. 1. Read all product instructions. 2. Keep printed instructions, do not throw away.
-
Page 4: Table Of Contents
VHD3200D · Contents Contents Introduction Introduction / Dimensions Getting Started Unpacking / Rack mounting / Cooling / AC Requirements Front Panel Rear Panel 6 - 7 Display menu description Remote management 9 - 12 Overview Channels Diagnostics Settings Specifications Warranty · Service... -
Page 5: Introduction
The unit acts as a slave for the VHD2000D, which provides audio and control signal. It can also be used with the EPAK2500/R when used in combination with KV2 Audio ES systems and power the associated ES subwoofer systems. -
Page 6: Getting Started
Unpacking Unpack the VHD3200D and check to see if there is any damage to it. If you find any damage notify your supplier immediately. Only the consignee may institute a claim with the carrier for damage incurred during shipping. Be sure to save the carton and all packing materials for the carrier's inspection. -
Page 7: Front Panel
1) AC Mains Switch The VHD3200D has combination AC mains switch/circuit breakers on the front panel. If either of the switches shut off during normal use, push it back to the ON position once. If it will not stay on you should take the unit to qualified service personnel to have it serviced. -
Page 8: Rear Panel
2) Bridge Mode Switch When operating the VHD3200D in bridge mode, (bridge switch pressed), Input A serves as a bridge mode input, bridge output (9) serves as speaker output. Input B is not active. 3) PowerCon Power Connectors The VHD3200D Amplifier uses two connectors per two channel. - Page 9 9) Bridge Mode AP4 Connector Output channel of the VHD3200D when running in Bridge Mono Mode. Do not connect other speakers to speakers outputs A & B in Bridge Mono Mode. The minimum recommended output load is 8Ω, when running in Bridge Mono Mode.
-
Page 10: Display Menu Description
VHD3200D Web-server The VHD3200D web-server is accessible using a standard web browser on PC or mobile device. The appropriate VHD3200D network address must be set to access web-server. The web-browser device IP address must be set from the same network range and must be connected into the same network. -
Page 11: Remote Management
VHD3200D · Remote management Web-server page Open the VHD3200D web-server, use the VHD3200D IP address, which is shown on display - section NET, or can be obtained using the KV2 diagtool software. Overview Shows the amplifier basic information. Basic Information Shows the information assigned by user of the amplifier: Description, Amplifier name, Location, Contact, Uptime and Firmware revision. -
Page 12: Channels
VHD3200D · Remote management Channels Shows the amplifier control parameters and amplifier diagnostics information. Control Mono mode (ON or OFF), Mute (RED = amplifier muted). Diagnostics Shows amplifier diagnostics information. Mains voltage Signal Green when input signal is present. Speaker protection Orange when speaker protection hits. -
Page 13: Diagnostics
VHD3200D · Remote management Diagnostics Shows the VH3200D amplifier and its components diagnostics information. Dual colour - Green = OK / Red = no power or some problem occurs. Device Sums VHD3200D diagnostics together. Channel A & B Sums amplifier channel diagnostics information: Power source, Temperature, Health (amplifiers A / B working OK with dedicated gain). Temperature Displays amplifiers heat sinks A & B temperatures (°C). -
Page 14: Settings
VHD3200D · Remote management Settings Shows and sets the device information, web-server password, network address. Device identification Shows and sets the device local information, Device name, Location, Contact. Security Sets name and password for web-server security (default User name: admin, default Password: admin). -
Page 15: Specifications
VHD3200D · Specifications Specifications Output Channels Number of Channels Out. Power 4Ω - 1 channel / 2 channels loaded 1600W / 1600W (RMS) Out. Power 8Ω - bridged 3200W (RMS) Low Frequency Amplifier Specification Type High efficiency, Low frequency, Current-enhancing switch mode Distortion <... -
Page 16: Warranty · Service
Service In the unlikely event that your VHD3200D develops a problem, it must be returned to an authorized distributor, service centre or shipped directly to our factory. Because of the complexity of the design and the risk of electrical shock, all repairs must be attempted only by qualified technical personnel. -
Page 17: Notes
VHD3200D · Notes... - Page 18 VHD3200D · Notes...
