Aufbauanleitung / assembly instructions mod. 2390 mit Mittenauszug M10 x 575 M8 x 25 SW17 30 x 10,5 1.Montagematerial. 2. Den Oberbau umgedreht auf gepolsterten 1. Fitting material. Montageböcken ablegen. 2. Put the table-top upside down onto padded assembling trestles.
Page 2
8. Before the extension can be pulled out, the two 7. While turning the table the feet must not touch black brake levers must be released. the ground and then put all the 4 table-legs onto the floor synchronistically. 2 / 5 2390 mit Mittenauszug Änderungsdatum: 21.08.17...
Page 3
Hauptplatte außen auf einer Höhe sind. Wenn nicht … 11. Check at the outer sides, if the upper surfaces of the board and the extension are on one level. If not ... 3 / 5 2390 mit Mittenauszug Änderungsdatum: 21.08.17...
Page 4
13b. … and keel over both pieces. extension at the same time ... Turn the scews of the black plastic-straps to adjust the hight. 4 / 5 2390 mit Mittenauszug Änderungsdatum: 21.08.17...
Page 5
14. Fertiger Tisch; nicht ausgezogen. 14. Finished table; not extended. 15. Fertiger Tisch; ausgezogen. 15. Finished table; extended. 5 / 5 2390 mit Mittenauszug Änderungsdatum: 21.08.17...
