- Page 1 Issue date Edition Doc No. JOHNSON Revision Edition time Page date PL219 MG Smith SERVICE MANUAL Approval Review Editor Hans Kong...
-
Page 2: Table Of Contents
Content CHAPTER 1：SERIAL NUMBER LOCATION................... 1 CHAPTER 2：MAINTENANCE & SAFETY....................2 CHAPTER 3: ASSEMBLY INSTRUCTION....................4 CHAPTER 4：TROUBLESHOOTING......................6 4.1 Weight Lifting Mast Is Not Level When Using................6 4.2 Steel Rope Fault..........................7 CHAPTER 5：PARTS REPLACEMENT..................... 8 5.1 Guide Rod............................8 5.2 Lifting Mast............................9 5.3 Steel Rope............................ -
Page 3: Chapter 1：Serial Number Location
CHAPTER 1：SERIAL NUMBER LOCATION... -
Page 4: Chapter 2：Maintenance & Safety
CHAPTER 2：MAINTENANCE & SAFETY IMPORTANT SAFETY INFORMATION It is the sole responsibility of the purchaser of MATRIX products to instruct all individuals, whether they are the end user or supervising personnel on proper usage of the equipment. It is recommended that all users of MATRIX exercise equipment be informed of the following information prior to its use. - Page 5 CHAPTER 2：MAINTENANCE & SAFETY PROPER USAGE 1. Do not exceed weight limits of the exercise device. 2. If applicable, set safety stops to appropriate height. 3. If applicable, adjust seat pads, leg pads, foot pads, range of motion adjustment, or any other type of adjustment mechanisms to a comfortable start position.
-
Page 6: Chapter 3: Assembly Instruction
CHAPTER 3: ASSEMBLY INSTRUCTION... - Page 7 CHAPTER 3: ASSEMBLY INSTRUCTION...
-
Page 8: Chapter 4：Troubleshooting
CHAPTER 4：TROUBLESHOOTING 4.1 Weight Lifting Mast Is Not Level When Using 1. Check if the ground or frame base is flat. 2. Check if the lifting mast is bent. 3. Check if the guide rod is bend or not vertical to the ground. 4. -
Page 9: Steel Rope Fault
CHAPTER 4：TROUBLESHOOTING 4.2 Steel Rope Fault 1. Check if steel rope body is broken. 2. Check if steel rope is properly connected to lifting mast or balance plate. 3. Check if steel rope is properly across the pulley. After finding the root problem, turn to the parts replacement section and replace the relevant part. -
Page 10: Chapter 5：Parts Replacement
CHAPTER 5：PARTS REPLACEMENT 5.1 Guide Rod 1. Remove the weight plate if needed. (Figure A) 2. Remove the rod stopper plate. (Figure B) 3. Lift the rod out of the slipping sleeve. (Figure C) 4. Reverse step 3-1 to restore. Figure A Figure B Figure C... -
Page 11: Lifting Mast
CHAPTER 5：PARTS REPLACEMENT 5.2 Lifting Mast 1. Remove the guide rods as section 5.1. 2. Disconnect the steel rope link to the mast. (Figure A) 3. Remove the whole lifting mast. 4. Remove the connect tube with fixing screw. (Figure B) 5. -
Page 12: Steel Rope
Figure C CHAPTER 5：PARTS REPLACEMENT 5.3 Steel Rope 1. Disconnect the rope link to mast as section 5.2. 2. Remove the pulleys. (Figure A) 3. Remove the stopper plate. (Figure B) 4. Pull out the balance plate and disconnect the other hand of steel rope. (Figure C) 5.
