Fluke ProcessMeter 789 Calibration Manual page 7

Figure
1. Replacing the Batteries and Fuses.......................................................................... 9
2. Verifying Loop Power............................................................................................ 12
3. Current Sourcing Connections Using the HP 3458A ............................................. 13
4. Current Measurement Test Connections ................................................................ 14
5. Diode Test Connections ......................................................................................... 16
6. Continuity Test Connections.................................................................................. 17
7. Resistance Measurement Test Connections ........................................................... 18
8. DC mV Measurement Test Connections................................................................ 20
9. AC/DC Voltage Measurement Test Connections .................................................. 21
10. Frequency Measurement Test Connections ........................................................... 23
11. Calibration Button Access...................................................................................... 26
12. Replacement Parts .................................................................................................. 31
List of Figures
Title
v
Page
