  • Page 1 OPERATING INSTRUCTIONS M72Z...

  • Page 2: Table Of Contents

    SPARE PART BOOK ......................- 50 - 10.0 NOTES ..........................- 81 - ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 2 -...

  • Page 3: Introduction

    TIP: Provides more information on functionality and tips for using the device efficiently. Appropriate protective clothing must be worn for all work on the described system. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 4: Description

    To press down the tyre bead at a third position A5 Assist-arm control For lifting and lowering the assist-arms ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 4 -...
  • Page 5 Press the pedal to swing the assembly tower backwards. Press it again to swing the assembly tower forwards again. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 6 A5.1 Control lever for the upwards and downwards movement of the assembly roller and bead pusher. A5.1 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 6 -...

  • Page 7: Operation

    Some wheels have a tyre pressure control system. This system may not be damaged on assembly or disassembly. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 8 Only used approved products! Repeat the procedure for the second wheel side. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 8 -...
  • Page 9 Adapter for standard rims Adapter for rims with a concave centre hole ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 9 -...
  • Page 10 For “reverse” rims For light truck rims ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 10 -...
  • Page 11 For rims with no inner hole For rims made from thin material ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 11 -...
  • Page 12 Secure the wheel by turning the complete quick-action chuck with the foldable handles. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 12 -...
  • Page 13 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 14 When working with tubular tyres, the tube should now be removed from the tyre. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 15 Cover the tyre and the wheel rim in a sufficient amount of assembly paste. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 16 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 16 -...
  • Page 17 In order to complete the process, release the wheel rim clamp to remove the wheel. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 18 2-3 km) ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 19: Technical Data

    1 = rim centre 2 = contact surface 1 inch = 2.54 centimetres ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 19 -...

  • Page 20: Scale Drawing

    Scale Drawing 1770-2170 mm 1120-1740 mm 1050-1550 mm ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 20 -...

  • Page 21: Installation

    Keep the packaging material out of the reach of children as it may be hazardous. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 22: Delivery Contents

    Tyre assembly iron Impact anchor Seal kit and membrane for rapid air vent ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 22 -...

  • Page 23: Location

    Humidity 50% at 40 °C – 90% at 20 °C Drawing ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 23 -...

  • Page 24: Fixing

    The compressed air maintenance unit must be serviced at regular intervals. The maximum or minimum pressure ensures perfect functioning without any damage. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 25: Hydraulic Connection

    Machine assembly must be carried out by a qualified and competent person. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 25 -...

  • Page 26: 2.10 Completion Of Work

    Warning: in some cases, this must be checked at regular intervals and tightened if necessary (note in the instructions). ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 27: Operation

     Annual check of the machine by an authorised and trained person ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 27 -...

  • Page 28: Basic Information

    Moving parts of the machine can catch loose clothing, long hair or jewellery. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 29: Maintenance

    Minimum requirement for truck mounting machine: Impact anchor M12 x 100 Compressed air system ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 29 -...

  • Page 30: Safety Regulations For Oil

    Oil is a combustible medium. Pay attention to possible hazards. Wear oil-resistant protective clothing, such as gloves, goggles, protective clothing, etc. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 31: Notes

    Check motor and transmission for function and wear Check welds and construction Visual inspection (according to inspection plan) ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 31 -...

  • Page 32: Troubleshooting / Error Display And Solutions

    ALWAYS USE ORIGINAL PARTS AND ACCESSORIES ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 32 -...

  • Page 33: Maintenance And Service Instructions

    Check the water level in the separator (2).  Water is drained when the valve (B) is opened. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 33 -...
  • Page 34 The swivel speed to the front and/or rear can be set by opening and/or closing the valves (A+B). ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 34 -...
  • Page 35 25 mm.  If necessary, refill with the required amount of oil. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 35 -...

  • Page 36: Disposal

    The machine contains some substances that can pollute the environment and cause harm to the human body if not handled correctly. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 37: Eg-/Eu-Konformitätserklärung / Ec-/Eu-Declaration Of Conformity

    BY MODIFICATION AND / OR CHANGES TO THE MACHINE, THE CE EXAMINATION IS EXCLUDED WITHOUT LIMITATION AND A LIABILITY SHALL BE EXCLUDED. ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 38: Appendix

    Pneumatic system assembly tower Pneumatic swivel cylinder Pneumatic breaking cylinder Pneumatic tyre inflator ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 38 -...

  • Page 39: Electric Circuit Diagram

    Electric circuit diagram ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 39 -...

  • Page 40: Hydraulic Circuit Diagram

    Hydraulic circuit diagram Not relevant! ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 40 -...

  • Page 41: Warranty Card

    ATH-Heinl within 24 hours) Place & Date Signature & Stamp ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 41 -...

  • Page 42: Scope Of The Product Warranty

    (overload, outdoor installation, technical changes) are excluded from the warranty! ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 43: Inspection Log

    Make a note of all the data below Manufacturer & type of mounting materials used: ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 44: Installation And Handover Log

    Operator name and company stamp Date and operator signature ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 44 -...

  • Page 45: Inspection Plan

    Condition / mechanical safety device Condition / functions under load Inspection sticker issued ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 45 -...

  • Page 46: Visual Inspection (Authorised Expert)

    Delete if not applicable Confirmation of operator or a representative with date and signature ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 47 Delete if not applicable Confirmation of operator or a representative with date and signature ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 48 Delete if not applicable Confirmation of operator or a representative with date and signature ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...
  • Page 49 Delete if not applicable Confirmation of operator or a representative with date and signature ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG...

  • Page 50: 9.0 Spare Part Book

    9.0 SPARE PART BOOK ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 50 -...
  • Page 51 Schraube M6x20 030201044 Screw M6x20 Beilagscheibe Ø6 030501004 Flat washer Ø6 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 51 -...
  • Page 52 Federscheibe Ø6 030502004 Spring washer Ø6 030301105 Mutter M6 Nut M6 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 52 -...
  • Page 53 Sprengring Ø12 030604005 Circlip Ø12 Grundplatte 23 RPE2001 05010060030 Bottom plate ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 53 -...
  • Page 54 05010060200 Switch holder Drehwendeschalter LW31-32 66 RWS6001 020401019 Double switch LW31-32 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 54 -...
  • Page 55 Bearing 32012 22 RAH2000 * 05010520074 Aufnahme für Hauptwelle/Drehteller Mainshaft sleeve ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 55 -...
  • Page 56 Schnellspannmutter kpl. RSM0196 *² RGW2003 Gewindewelle kpl. mit Zugring Drehtelleraufnahme kpl. RDA2000 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 56 -...
  • Page 57 Getriebe / Gear box ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 57 -...
  • Page 58 20 RKL0880 030802003 Bearing 6208 030604043 Sprengring Ø50 Circlip for shaft Ø50 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 58 -...
  • Page 59 Hexagon screw M10 0520118160 Motor komplett Three phases motor assembly C ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 59 -...
  • Page 60 Montiersäule / Horizontal arm ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 60 -...
  • Page 61 Screw M6x12 RAM0003 020601177 Abdeckung Montageturm Protect panel Haken RHA2003 05010020444 Hook ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 61 -...
  • Page 62 Montageturm Ausleger / Vertical arm ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 62 -...
  • Page 63 Cylinder assy 34 RVA0002 060109043 Montageturm Ausleger komplett Cross arm assy ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 63 -...
  • Page 64 Schwenkzylinder / Buffer cylinder ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 64 -...
  • Page 65 Rubber ring Bolzen für Neigezylinder unten Connecting axle 1 RBS0002 05010020430 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 65 -...
  • Page 66 Screw M6x35 RYR8000 0530102432 V-Dichtung Ø60x47x7 Pistion Gehäuse 020502009 Y-ring Ø60x47x7 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 66 -...
  • Page 67 Screw M6x35 V-Dichtung Ø60x47x7 RYR8000 020502009 Y-Ring Ø60x47x7 Kolben 05010020432 Pistion ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 67 -...
  • Page 68 Valve holder Handventil Buchse 020601169 Valve sleeve Ventilknopf RHK8001 020601094 Valve button ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 68 -...
  • Page 69 Flat washer Ø16 RSA0003 060104040 Abdrückarm komplett Brad breaker blade (H) ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 69 -...
  • Page 70 Zylinder für Abdrücker / Bead breaker cylinder ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 70 -...
  • Page 71 Schnellentlüftung (E) 19 RSE1210 0520116050 Bead cylinder quick valve assy (E) ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 71 -...
  • Page 72 020203080 Thread G1/4“-G1/4“ RSE1209 0520116020 Schnellentlüftung (B) Handle control valve (B) ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 72 -...
  • Page 73 020203024 Fitting Ø10-G1/8“ Schnellentlüftung (E) RSE1209 0520116020 Handle control valve (E) ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 73 -...
  • Page 74 Tube Ø8 - Ø5 3 RRF8001 0520119010 Reifenfüller komplett Inflation gun assy ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 74 -...
  • Page 75 Fitting Ø8-G1/4“ 5 RWE8000 060108031 Druckluftwartungseinheit DFC-2010A(G) Air regulator assy DFC-2010A(G) ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 75 -...
  • Page 76 Hilfsarm / Assist arm ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 76 -...
  • Page 77 05030020210 Tire press pad RNR0001 020601089 gerade Niederhalterolle Tire press roller ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 77 -...
  • Page 78 Beilagscheibe Ø10 030501006 Flat washer Ø10 Schraube M6x20 030201044 Screw M6x20 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 78 -...
  • Page 79 Sprengring Ø10 Spring washer Ø10 030501006 Beilagscheibe Ø10 Flat washer Ø10 ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 79 -...
  • Page 80 Schraube M10x25 Screw M10x25 73* RDS2000 Dichtsatz Zylinder kpl. Seal-kit cylinder complete ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 80 -...

  • Page 81: 10.0 Notes

    10.0 NOTES ® Copyright ATH-Heinl GmbH & Co. KG, 2019, All rights reserved / Misprints and technical changes reserved / As of: 2019-03 Manufacturer ATH-Heinl GmbH & CO.KG - 81 -...
