Installation and Safety Instructions
for United States and Canada
and IEC version
THIS DOCUMENT APPLIES TO THE FOLLOWING
RECOM PHOTOVOLTAIC MODULES:
60 Cell Monocrystalline Silicon Modules:
RCM-xxx-6MB (xxx=250-310)
60 Cell Polycrystalline Silicon Modules:
RCM-xxx-6PB (xxx=240-280)
72 Cell Monocrystalline Silicon Modules:
RCM-xxx-6MA (xxx=290-360)
72 Cell Polycrystalline Silicon Modules:
RCM-xxx-6PA (xxx=290-340)
Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5
RECOM © Copyright 2018
UL AND IEC INSTALLATION GUIDE
p. 1 of 14
www.recom-solar.com
Advertisement
Table of Contents
Related Manuals for Recom RCM 6MB Series
Summary of Contents for Recom RCM 6MB Series
- Page 1 RCM-xxx-6MB (xxx=250-310) 60 Cell Polycrystalline Silicon Modules: RCM-xxx-6PB (xxx=240-280) 72 Cell Monocrystalline Silicon Modules: RCM-xxx-6MA (xxx=290-360) 72 Cell Polycrystalline Silicon Modules: RCM-xxx-6PA (xxx=290-340) Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5 p. 1 of 14 RECOM © Copyright 2018 www.recom-solar.com...
-
Page 2: Table Of Contents
Planning and Design Modules Wiring 5. MOUNTING CONFIGURATIONS 6. GROUNDING & ELECTRICAL WARNINGS 7. DISCLAIMER OF LIABILITY 8. DECOMMISSIONING AND RECYCLING 9.PRODUCT INFORMATION Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5 p. 2 of 14 RECOM © Copyright 2018 www.recom-solar.com... -
Page 3: Introduction
UL AND IEC INSTALLATION GUIDE 1. INTRODUCTION Thank you for selecting RECOM Photovoltaic Modules. The RECOM Photovoltaic Modules are designed and manufactured to the highest quality standards. With correct installation and maintenance, RECOM modules will keep providing clean energy for many years. -
Page 4: Storage, Unpacking And Handling
Do not mark the modules with sharp instruments. • Do not leave a module unsupported or unsecured. • Do not modify module frames in any way. Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5 p. 4 of 14 RECOM © Copyright 2018 www.recom-solar.com... -
Page 5: Safety
If dirt or debris becomes built-up clean the glass using only a soft cloth, with a mild, non-abrasive de- tergent and water. RECOM recommends using mild cleaning liquids; a neutral pH in the range of 6.0 to 8.0 is recommended. -
Page 6: Mechanical Installation
• All RECOM solar modules have a module fire resistance rating of Class Per UL 1703, the fire rating of this module is valid only when mounted in the manner specified in the mechanical mounting instructions. The system fire rating is determined by the module, rack and roofing materials. -
Page 7: General Installation Guidelines
Mechanical installation of the module shall not cause the frame to torque more than 38 mm. • A minimum clearance of 152 mm is required between the roof and bottom of the module frame. Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5 p. 7 of 14 RECOM © Copyright 2018 www.recom-solar.com... -
Page 8: Electrical Installation
There is no limit to the maximum number of series strings that can be combined in parallel. However, each string must include overcurrent protection with a maximum rating of 15 A. RECOM recommends the use of Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5 p. - Page 9 In colder climates, it may be necessary to further reduce the maximum number of modules in a series by using Vocm at the minimum expected operating temperature. Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5 p. 9 of 14 RECOM © Copyright 2018 www.recom-solar.com...
-
Page 10: Mounting Configurations
Clamp Mount Range as shown in the color code key. FRONT VIEW Clamp Mount Locations: Clamp mount allowable range BACK VIEW Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5 p. 10 of 14 RECOM © Copyright 2018 www.recom-solar.com... - Page 11 A - 394 mm D - 400 mm F - 200 mm Clamp Mount allowable range: C - 444 mm E - 1188 mm Installation Instructions UL-1703 and IEC / Rev. 05-2018 V.5 p. 11 of 14 RECOM © Copyright 2018 www.recom-solar.com...
-
Page 12: Grounding & Electrical Warnings
• RECOM modules use a coated aluminum frame for corrosion resistance. In order to ensure proper ground- ing the coating must be penetrated by the grounding method. A copper grounding wire with a minimum gauge of 12 AWG is recommended to carry the electrical ground load. -
Page 13: Disclaimer Of Liability
• The information in this manual is based on RECOM’s best knowledge and experience and is believed to be reliable; but such information including product specification (without limitations) and suggestions do not constitute a warranty, express or implied. RECOM reserves the right to change the manual, the PV product, the specifications, or product information sheets without prior notice. -
Page 14: Product Information
UL AND IEC INSTALLATION GUIDE 9. PRODUCT INFORMATION Structural Drawings The engineering drawing shown belongs to the following listed RECOM Module Series: RCM 330/335/340/345/350/355-6MA PHYSICAL PARAMETERS Module Weight: Dimension inch Dimension inch 21.2 Kg MOUNTING HOLE SPACING MODULE DIMENSIONS Frame Material: 37.4...
