NI R Series Getting Started Manual

Reconfigurable i/o module for pxi express
Hide thumbs Also See for R Series:

Advertisement

Table of Contents

GETTING STARTED GUIDE
NI PXIe-7865
R Series Reconfigurable I/O Module (AI, AO, TTL-compatible DIO) for
PXI Express, 2 AI, 24 AO, 32 TTL-compatible DIO, 1 MS/s AIO,
512 MB DRAM, Kintex-7 160T FPGA
This document describes how to begin using the NI PXIe-7865.
Unpacking the Kit
Notice
To prevent electrostatic discharge (ESD) from damaging the device, ground
yourself using a grounding strap or by holding a grounded object, such as your
computer chassis.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R Series and is the answer not in the manual?

Questions and answers

Related Manuals for NI R Series

Summary of Contents for NI R Series

  • Page 1 GETTING STARTED GUIDE NI PXIe-7865 R Series Reconfigurable I/O Module (AI, AO, TTL-compatible DIO) for PXI Express, 2 AI, 24 AO, 32 TTL-compatible DIO, 1 MS/s AIO, 512 MB DRAM, Kintex-7 160T FPGA This document describes how to begin using the NI PXIe-7865.

  • Page 2: Verifying The Kit Contents

    LabVIEW Real Time Module is only required when the R Series board is used in a chassis where the PXIe Controller is running a real-time operating system. 2 | ni.com | NI PXIe-7865 Getting Started Guide...
  • Page 3 5. PXI Express Peripheral Slot 3. PXI Express Hybrid Peripheral Slot NI PXIe-7865 modules can be placed in PXI Express peripheral slots, PXI Express hybrid peripheral slots, or PXI Express system timing slots. Touch any metal part of the chassis to discharge static electricity.
  • Page 4 10. Power on the chassis. Verifying Hardware Installation for Host Targets You can verify that the system recognizes the NI PXIe-7865 by using Measurement & Automation Explorer (MAX). Launch MAX by navigating to Start»All Programs»National Instruments»MAX or by clicking the MAX desktop icon.
  • Page 5 SCB-68A accessory. Note NI is not liable for connections that exceed any of the maximum ratings of input or output signals on the NI PXIe-7865 and on the computer chassis. Refer to the NI PXIe-7865 Specifications, available at ni.com/info for the maximum input and output ratings for each signal.
  • Page 6 Negative analog input signal connection AISENSE Reference connection for NRSE measurements AIGND Ground reference for the analog input signal Analog output signal connection AOGND Ground reference for the analog output signal 6 | ni.com | NI PXIe-7865 Getting Started Guide...
  • Page 7 Note The pinout label on the lid of the SCB-68A accessory is incompatible with the NI PXIe-7865. Refer to the NI 78xxR Pinout Labels for the SCB-68A, available ni.com/manuals for the compatible pinout labels. | © National Instruments | 7...

  • Page 8: Where To Go Next

    NI. NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. NI also has offices located around the world. For support in the United States, create your service request at ni.com/support...
  • Page 9 United States, visit the Worldwide Offices section of ni.com/niglobal access the branch office websites, which provide up-to-date contact information. | © National Instruments | 9 NI PXIe-7865 Getting Started Guide...
  • Page 10 . You can find patents.txt ni.com/patents information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at for the NI global trade compliance policy and how ni.com/legal/export-compliance...
