- Page 1 STYLOS Credential reader User Manual EN 02...
-
Page 3: Information Icons
About this manual Dear Customer, Thanks for choosing this innovative ISEO product, designed and developed following the highest standard of production, for an effective user-friendly and, at the same time, powerful and flexible access control. This manual explains the functions, configurations and characteristics of Stylos, the ISEO credential reader. -
Page 4: Information On Copyright
ISEO. • ISEO reserves the right to change the specifications of the hardware and software described in this manual at any time and without prior notice. -
Page 5: Table Of Contents
Information icons 21 Introduction Information on copyright 22 Stylos opening Multiblindo eMotion Trademarks 23 Stylos opening Serie 5 electric lock Keywords 24 Stylos opening Trim Tronic 25 Stylos opening ISEO Automatic Swing Door Operator IS9100 26 Stylos opening Thesis 2.0... -
Page 6: Safety And Environment
• Read this manual prior to use the device in order to ensure a safe and proper use. • Preserve this manual as future reference. • The installation of the device requires the intervention of qualified staff, adequately trained by ISEO. • The instructions should be carefully followed during installation. These instructions and any mainte- nance instructions should be passed on by the installer to the user. -
Page 7: Handling Lithium Batteries
Safety and Environment Handling lithium batteries Batteries may leak or explode if improperly handled. Observe the following precautions when handling batteries for use in this product: • Do not connect the battery during the shipping and the storage. Connet the battery just during installation and use. -
Page 8: Disposal And Recycling
Safety and Environment Disposal and recycling This product and battery are designated for separate collection at an appropriate collection point. Do not dispose of as household waste. For more information, contact the retailer or the local authorities in charge of waste management. Dispose of the product separately from household waste, in accordance with local laws and regulations. -
Page 9: Certifications
In conformity with the essential requirements and other relevant requirements of the: Directive 2014/53/EU (RED) Donwload the conformity certificate at iseo.com website Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields), recommended by international guidelines. -
Page 10: Overview
Overview What is Stylos Stylos is a multistandard ISO 14443 A/B credential reader that in combination with the Electric Lock Actuator, is able to control any electrical. Stylos Smart version embeds the Bluetooth Smart Technology, in order to work with Argo, the ISEO application running on iOS and Android smartphone. -
Page 11: Technical Data
Acoustic buzzer. Keyboard (only Display version) 12 buttons with backlight controlled from firmware. Software V364 Software. VAR/OEM development platform available. Argo app available for Android and iOS phones (Stylos Smart). Software upgrade on site. Assembly Wall assembly. Spacer available Lockbus interface 3 wires multipoint serial bus for power and data. - Page 12 Secure device authentication (among readers and actuators) and encrypted data transmission for high security against manipulation. Environmental characteristics Operating temperature: 0°C ÷ +60°C. Storage temperature: -25°C ÷ +75°C. Protection system (IP grading): IP54 For detailed commercial information, please check related catalogue and leaflet at: iseo.com.
-
Page 13: Dimensions
Overview Dimensions Dimensions (mm) A = 47,50 B = 17,50 C = 130... -
Page 14: Options And Versions
Overview Options and versions Stylos can be supplied in different version: Stylos LED, Stylos Display with keyboard and Stylos All Weather (only LED version). For more detailed information go to the on-line catalogue at iseo.com website. 1) Stylos LED 2) Stylos Display with keyboard... - Page 15 Overview 3) Stylos All Weather (IP66 Outdoor version - only LED version) Stylos All Weather is composed by 3 units. 1. IP66 Credential reader module (outdoor). • The module encloses the RFID contactless multi- standard reader, completeley sealed for outdoors installation, to resist against rain, snow and humi- dity exposure (IP66).
- Page 16 OUT DO OR S IDE IN D O O R S ID E Connection cable: max 5mt lenght Credential reader Control unit For more information about Stylos and Stylos All Weather installation, refer to the Installation Guides available at: iseo.com.
-
Page 17: Accessories
• DIN35 rail housing Controlled by Stylos allows to open any electrical device. Lockbus interface Electric Lock Actuator dimensions: For more information about the Electric Lock Actuator installation, read to the Installation Guides or... - Page 18 Overview B) Power supply The Stylos Line products are provided with a self-adjusting power supply from 8Vdc to 30 Vdc, ensuring top flexibility and allowing in most cases the use of an existing supply even when the theoretical parameters are deteriorated.
-
Page 19: Getting Started
Getting Started Package contents The product box contains the following items: • Stylos. • 2 screws for metal. • 2 screws for plastic. • 2 washers. • 2 fisher adaptors. • Installation guide. The items supplied with the Device and any available accessories may vary depending on the region or... -
Page 20: Installing Stylos
For a correct procedure see also Warnings at the Safety and Environment chapter. Programming and using Stylos For these operations, please refer to Argo User Manual for Stylos Smart, or V364 System Administra- tor Manual for Stylos. Both available at: iseo.com. -
Page 21: Introduction
Installation examples Introduction Stylos in combination with the Electric Lock Actuator is able to control any electrical devices: like bars, electric gates, sliding doors, turnstiles, or automatic swing door operator. Electric cable Lockbus cable* * It is hereinafter referred as “Lockbus cable” the communication cable between Stylos and Actuator, since communication take place via the ISEO proprietary Lockbus protocol. -
Page 22: Stylos Opening Multiblindo Emotion
In this example, to simplify the scheme, it has been used a single power supply to power all devices. On real plants scenario, for ser vice and maintanance purpose, it is usually recommended to sepa- rate Stylos and Actuator power supply from the electrical device (in this case Multiblindo eMotion), by using 2 different power supply properly dimensioned. -
Page 23: Stylos Opening Serie 5 Electric Lock
Lockbus To know more about wires minimum cross-section and power supply sizing go to Cable sizing paragraph. For more technical information about wiring and connections, refer to the device’s installation guides, included in the device’s box or available at: iseo.com. -
Page 24: Stylos Opening Trim Tronic
Lockbus To know more about wires minimum cross-section and power supply sizing go to Cable sizing paragraph. For more technical information about wiring and connections, refer to the device’s installation guides, included in the device’s box or available at: iseo.com. -
Page 25: Stylos Opening Iseo Automatic Swing Door
Installation examples Stylos opening ISEO Automatic Swing Door Operator IS9100 12VDC / 3A Lockbus To know more about wires minimum cross-section and power supply sizing go to Cable sizing paragraph. For more technical information about wiring and connections, refer to the device’s installation guides,... -
Page 26: Stylos Opening Thesis 2.0
Lockbus Thesis 2.0 embeds the Lockbus communication interface, therefore it can be connected directly to Stylos without the need of the Electric Lock Actuator. To know more about wires minimum cross-section and power supply sizing go to Cable sizing paragraph. - Page 27 Lockbus To know more about wires minimum cross-section and power supply sizing go to Cable sizing paragraph. For more technical information about wiring and connections, refer to the device’s installation guides, included in the device’s box or available at: iseo.com.
-
Page 28: Cable Sizing
For cable sizing purpose we need to take in consideration the Lockbus communication protocol between Stylos and actuators (Electric Lock Actuator and Thesis 2.0). Lockbus is a power ful multipoint bus, sharing data transmission and power supply on the same 3 wires connection, for utmost flexibility, easy installation and consequently, cost optimization. -
Page 29: Lockbus And Power Supply Unit Sizing Calculation Example
From 75 to 100 • 13 • 2,5 Lockbus and power supply unit sizing calculation example Referring to the previous installation example Stylos opening Multiblindo eMotion, let’s properly size the Lockbus cable and the power supply unit. 12VDC / 3A Lockbus... - Page 30 Electric Lock Actuator Power supply: 8/30 Vdc – 0,5A Power consumption: 3 W Placed inside the house, in a box, nearby the main entrance. Distance from Stylos: 2mt Lockbus communication protocol Multiblindo eMotion Power supply: 11 ÷ 14 Vdc Maximum absorbed current: 1,5A Power supply minimum characteristics: 12 Vdc / 2A (30W) Distance from power supply 1.5mt.
-
Page 31: Maintenance
Maintenance Battery replacement Stylos has an internal cell type lithium battery used to keep date and time synchronizations. When Stylos is installed and powered from mains this battery is not used. The average lithium cell battery life is about 10 years. - Page 32 Maintenance 2. Disconnect the Stylos connector plug. 3. Remove the ESD protection. Back view Back view Circuit side Circuit side LITHIUM LITHIU LITHIUM CR2032 CR2032...
- Page 33 If the battery is disconnected for more than 5 minute, the Device clock might go out of synchronization. To synch the clock: • Stylos Smart: enter Programming Mode with Master Card and the door lock will automatically take smartphone date and time.
-
Page 34: Cleaning
Storage • For not installed product, store Stylos in a clean dry place at a room temperature between -25°C and +75°C and relative humidity between 20% and 95%. • For a better storage, use the original packing box. -
Page 35: Troubleshooting
• Check Actuator power supply if • Faulty control unit*. present. *Only All Weather version. • Replace Control unit. For Stylos spare part codes, refer to the on-line catalogue available at iseo.com or call the ISEOZero1 Technical Support (go to Technical assistance). -
Page 36: Light And Acoustic Signals
For this topic go to “Light and acoustics signals” in the Argo User Manual or in the V364 System Administrator Manual, both available at iseo.com. Technical assistance For any help please contact ISEOZero1 Technical Support. Visit iseo.com website to find your country telephone number. When you contact the ISEOZero1 Technical Support please provide the next information: •... - Page 37 Notes...
- Page 38 ASIA ISEO Asia Pacific SDN. BHD. zero1-asia@iseo.com +603 80753331 ISEO Beijing zero1-cn@iseo.com +8610 58698079 UNITED ARAB EMIRATES Iseo Projects and Access Control DMCC iseoprojects@iseo.com +971 4 5136162 SOUTH AFRICA ISEO South Africa (Pty) LTD zero1-za@iseo.com ROMANIA Feroneria Prod S.A. zero1-ro@iseo.com...
