FUNCTION OVERVIEW

2
3
2
2
Serial
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
6
5
4
19
2
1
12
16
Define
on/off
up and down, Left and
Right
ok
menu
Signal source
focusing ring
Keystone Correction
VGA/Computer
HDMI
Compound video input
interface
3.5mm headphone jack
the USB interface
SD card
IR force control head
Speaker
Power input
Air outlet
D-TV interface
Power LED
15
8
17
Describe
on/off
multi-function up and down,
left and right
function to confirm
menu display
source display
resolution adjustment
+15 adjustment picture keystone out alignment
Computer input or other VGA output devices
connect HDMI input or other HDMI output device
3-in-1 switching line access composite video
signal
headphone jack or active speaker jack
Connect the USB disk or move the hard disk/mouse
SD card slot
remote reception signal
Built In Speaker
For main power connection
For perfect airflow inside projector
To Connect D-TV Connections
For Standby Status
13 9
14 11 10
18
7
