Linak TECHLINE LA36 Connection Diagram page 3

I/O Specifications
Without feedback
Input/Output
Description
Brown
Blue
Red
Black
Green
Yellow
Violet
White
F O R M O U N T I N G I N S T R U C T I O N S A N D G U I D A N C E I N U S A G E , P L E A S E S E E T H E R E L E V A N T U S E R ' S M A N U A L S
Specification
Permanent magnetic DC motor.
12, 24 or 36* VDC (+/-)
*Only available on LA36
12V ± 20%
24V ± 10%
36V ± 10%
Under normal conditions:
12V, max. 26A depending on load
24V, max. 13A depending on load
Not to be connected
Not to be connected
Not to be connected
Not to be connected
Not to be connected
Not to be connected
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
4
2019 © LINAK A/S
