- Page 1 Installation Manual -G006 Corner Climber YM11554 63 ½” (1.61m) (0.51m) (0.51m) (0.69m) (0.69m) Yardistry Ltd. Mount Forest, ON Canada N0G 2L1 Toll Free Customer Support: 1.888.509.4382 info@yardistrystructures.com www.yardistrystructures.com Revised 08/24/2011...
- Page 2 Tools Required Warranty: Yardistry Limited products are backed by a 5 year limited lifetime warranty from the date of original retail purchase for manufacturing defects and if installed as per manufacturer’s installation instructions. • Tape Measure •...
- Page 3 Material List Top and Bottom Rail -2x 7 1/4” (18.4cm) and 2x 20” (50.8cm) #8 x 2 1/4” Wood Screw #10 x 1” Pan Head Screw #8 x 1 1/2” Wood Screw (3) Post Caps (12) Panel Clips (2)Arch Topper (2) Two High X Panel...
- Page 4 Insert male into female. Slide down until flush with also be connected together as Panels if required. à deux ou à trois carreaux de hauteur 20" altos a medida que se adquieran. adjacent panel. purchased. (vendus séparément). os paneles. *Use los tornillos de acero inoxidable *Use 2 1/4"...
- Page 5 Step 2- Attach Panel Clips For Wings 1. O n a flat surface place P- 4x4 Post on its side and position Panel Clips in Fig. 2 locations indicated in Figures 1 and 1A. Ensure Panel Clips are oriented as shown in Diagrams! 2. Panel Clips should be placed in the centre of the post or the leading edge of the clip should be 1 3/8” or 3.49cm away from the side of the post as shown in Fig. 2. 1 3/8”...
- Page 6 Step 3- Attaching Post Caps 1. Place a Post Cap on each 4x4 Post 2. S ecure Post Cap with 2 S7- #8- 1 1/2” Wood Screws 3x Post Caps #8- 1 1/2” Wood Screws...
- Page 7 This identifies information that requires special Check that set or assembly is properly level Step 4- Attach Wings to Posts attention. Improper assembly could lead to an before proceeding. unsafe or dangerous condition. Pre-drill 1/8” & 3/16” Bit Where this is shown, 2 or 3 Help Help 1. P lace panel assemblies on posts as shown (Fig.1) allowing a 2” gap between...
