  • Page 2: Explanation Of Graphical Symbols

    WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. TX6n/5n/4n Owner’s Manual Explanation of Graphical Symbols The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 3: Fcc Information (U.s.a.)

    * This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. COMPLIANCE INFORMATION STATEMENT (DECLARATION OF...
  • Page 4 If any liquid such as water seeps into the device, turn off the power immediately and unplug the power cord from the AC outlet. Then have the device inspected by qualified Yamaha service personnel. • Never insert or remove an electric plug with wet hands.
  • Page 5 Use only Neutrik NL4 plugs for connecting Speakon connectors. Yamaha cannot be held responsible for damage caused by improper use or modifications to the device, or data that is lost or destroyed. Always turn the power off when the device is not in use.

  • Page 6: Table Of Contents

    If you have installed a fan kit, there may be cases in which closing the back of the rack will provide better cooling. For details, refer to the instructions that came with the rack system or fan kit. TX6n/5n/4n Owner’s Manual Contents...

  • Page 7: Introduction

    Thank you for purchasing the Yamaha TX6n, TX5n, TX4n Power Amplifier. In order to take full advantage of the TX6n/TX5n/TX4n’s (TXn) functionality and to ensure trouble-free operation, please read this owner’s manual carefully before use. After you have read the manual, keep it in a safe place for reference when needed.

  • Page 8: Firmware Updates

    If you will not be using this device for an extended period of time, be CAUTION sure to disconnect the power plug from the AC outlet. TX6n/5n/4n Owner’s Manual [MUTE] buttons [ENTER] button Function buttons [HOME] button...

  • Page 9: Basic Operation Of The Txn

    To display the meter, access the HOME screen and press the left-most function button (METER). You can change the meter type by using the left-most function button (PREV) and the right-most function button (NEXT). Encoder B Attenuator Level meter TX6n/5n/4n Owner’s Manual...

  • Page 10: Operations That Can Be Performed From The Panel

    Basic Operation of the TXn Operations that can be Performed from the Panel • For details, refer to the TX6n/5n/4n Reference Manual. NOTE Category Subcategory METER ANA INPUT VOLTAGE SLOT INPUT VOLTAGE SP OUTPUT VOLTAGE SP OUTPUT POWER SP OUTPUT IMPEDANCE...

  • Page 11: Audio I/O Settings

    This setting can be changed from the panel of the TXn or via Amp Editor. For details on making this setting, refer to “TX6n/5n/4n Reference Manual” or “Amp Editor Owner’s Manual.” • Use 110-ohm AES/EBU digital cables for digital audio connections. Using analog cables may degrade the sonic quality.

  • Page 12: Bridge Mode

    Sensitivity, and encoder B to edit the parameter value. If the parameter value is blinking, press the [ENTER] button to confirm the value. • Refer to the TX6n/5n/4n Reference Manual for details NOTE on the gain. Word Clock Setting If you want to input or output digital audio signals, you must check the word clock settings as necessary.

  • Page 13: Wiring Of The [Speakers] Connectors

    Neutric NL4 plugs – CHANNEL A Stereo/Parallel Mode Neutrik Amplifier 1– A– 2– B– Bridge Mode Neutrik Amplifier 1– – 2– CHANNEL B Neutrik Amplifier 1– B– TX6n/5n/4n Owner’s Manual –...

  • Page 14: Network Connection Example

    • To prevent electromagnetic interference, use an STP (Shielded Twisted Pair) cable. • Refer to the Amp Editor Installation Guide and the Amp Editor Owner’s Manual for information on the TXn initial setup for using the TXn in a network. TX6n/5n/4n Owner’s Manual Device ID: 1 IP Address: 192.168.0.1 Device ID: 2 IP Address: 192.168.0.2...

  • Page 15: Troubleshooting

    For details on the meaning of each alert message and the appro- priate measures to take, refer to the Amp Editor Owner’s Manual. Refer to “Front Panel Operation” in the TX6n/5n/4n Reference Manual. Turn the UTILITY screen → Scene Setup → Scene Recall Enable setting ON.

  • Page 16: Specifications

    Analog input to speaker output AES/EBU input to speaker output Analog input to AES/EBU output AES/EBU input to AES/EBU output AES/EBU input to AES/EBU though output Controls Front panel TX6n/5n/4n Owner’s Manual TX6n TX5n 120V 230V (*1) 120V 230V (*1)
  • Page 17 Variable speed fan : x 2 U.S./Canada: 120V, 60Hz Korea: 220V, 60Hz China: 220V, 50Hz Other: 220V-240V, 50/60Hz TX6n: 1800W, TX5n: 1600W, TX4n: 1500W 1.5m 480mm x 88mm x 461mm; 18-7/8" x 3-7/16" x 18-1/8" 16kg; 35.3lbs 0˚C to +40˚C -20˚C to +60˚C...

  • Page 18: Block Diagram

    Specifications Block Diagram SENSE SENSE CLIP TX6n/5n/4n Owner’s Manual...

  • Page 19: Level Diagram

    Delay PEQ Level MUTE Limiter Delay Over [Speaker Processor] Delay Level Pol. Delay PEQ Level MUTE Limiter Over Specifications POWER TX6n Clips (43.8dBu) TX5n Clips TX4n Clips Model Maximum Output Power TX6n 43.8dBu (1800W/8Ω) TX5n 42.4dBu (1300W/8Ω) TX4n 41.2dBu (1000W/8Ω) ATT: -∞dB...

  • Page 20: Dimensions

    Specifications Dimensions Unit: mm TX6n/5n/4n Owner’s Manual...

  • Page 21: Current Draw

    1077 3670 1383 4720 1190 1070 1470 2310 1810 2810 1257 4290 1080 1220 2030 1390 2340 1106 3780 TX6n FREQUENCY RESPONSE INPUT : ANALOG OUTPUT LOAD : 8ohm 0dBr=1W Fs=96kHz GAIN : 32dB ATT : MAX TX6n/5n/4n Owner’s Manual...
  • Page 22 Information for Users on Collection and Disposal of Old Equipment This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in accordance with your national legislation and the Directives 2002/96/EC.

  • Page 23: North America

    For details of products, please contact your nearest Yamaha representative or the authorized distributor listed below. Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou au distributeur le plus proche de vous figurant dans la liste suivante.
  • Page 24 Yamaha Pro Audio global web site: http://www.yamahaproaudio.com/ Yamaha Manual Library http://www.yamaha.co.jp/manual/ U.R.G., Pro Audio & Digital Musical Instrument Division, Yamaha Corporation © 2009 Yamaha Corporation WP58530 003POZCx.x-03C0 Printed in Indonesia...
