LED Lighting System
(GEXNLG15, GERDXNLG15, GEPOXNLG15, GEYAXNLG15, GELGXNLG15,
GEGLXNLG15, GEBLXNLG15)
Step 1:
Preparation
1
Remove the protective film from the light guide.
3
Cut the light guide to the required length using a
hacksaw, chop saw (cross cut or veneer blade only),
band saw, or other appropriate plastic cutting tool.
Take the proper safety precautions when cutting the
light guide.
imagination at work
Forming Instructions
2
Mark the light guide at the required length, adding
0.5 in. (13mm) for every 16 in. (406mm) to account
for shrinkage during the forming process.
4
Fill the entire light guide channel with the Silicone
Bend-Aid(s) (GEXNBA) and press into place. Bend-Aid
must be installed prior to heating and forming.
NOTE: The Silicone Bend-Aid (GEXNBA) is reusable.
Light Guide
Silicone Bend-Aid
