GEZE TSA 325 NT Translation Of The Original Instructions
Revolving doors
Hide thumbs
Also See for TSA 325 NT:
- Wiring diagram (68 pages) ,
- Installation instructions manual (112 pages)
Related Manuals for GEZE TSA 325 NT
Summary of Contents for GEZE TSA 325 NT
- Page 1 TSA 325 NT Translation of the original instructions GB User manual Revolving doors...
-
Page 2: Table Of Contents
Automatic revolving door All-glass Break-out function Underfloor drive Manual night locking system Automatic night locking system Internal manual night locking system Internal automatic night locking system IANV Example: TSA 325 NT BO = Revolving door TSA 325 NT with break-out function... -
Page 3: About These Instructions
Observe any relevant additional country-specific and European directives. Operating, maintenance and repair conditions specified by GEZE must be observed. Maintenance and repair work may only be performed by properly trained personnel authorised by GEZE. Only trained, GEZE-authorised personnel may remove the hood/cover. -
Page 4: Description
Description TSA 325 NT Description 3. 1 Structure The operating elements are arranged differently depending on the situation. For technical reasons, we cannot show all of the possibilities here. The door system shown is only a schematic diagram. System parts and options... -
Page 5: Operation
Operation 4. 1 Normal door operation GEZE revolving doors can be operated with special control elements, which deviate from the behaviour de- scribed here. Please ask the responsible service technician for information on the special control elements which are installed. - Page 6 Operation TSA 325 NT Operating mode TPS-KDT Descriptions Automatic All the connected pulse generators are active in the "Automatic" operating mode. Revolving speed and follow-up time can be set. When triggered by a movement detector the door acceler- ates to the set automatic speed, continues to turn at this speed and stops after a preset number of sectors in the target position.
- Page 7 TSA 325 NT Operation Operating mode TPS-KDT Descriptions Night Manual locking A bolt lock can be used as a manual locking element. A contact used to monitor the locking operating mode can be mounted. Unlocking Locking Unlock lock. Unlock lock.
-
Page 8: Locking/Unlocking (Optional)
No power supply TSA 325 NT Operating mode TPS-KDT Descriptions Night Optional Revolving door suitable for use in escape and rescue routes. During slow travelling into the end position press the key-operated switch and keep it pressed. The door locks automatically in the end position. -
Page 9: Fault Messages At The Tps-Kdt
TSA 325 NT Fault messages at the TPS-KDT Fault messages at the TPS-KDT If a fault occurs in the system, an fault code is shown every 5 seconds alternatively to the operating mode. Up to 20 different fault messages can be displayed. - Page 10 What to do if...? TSA 325 NT Problem Cause Remedy Door does not rotate Movement detector mis- Check movement detector. aligned or defective "Night", "Off" operating Select another operating mode. mode "Shop closing time" operat- Select "Automatic" operating mode. ing mode Door is locked manually Unlock the door.
-
Page 11: Cleaning And Maintenance
The owner must ensure that the system functions properly. If the "Winter" LED at the TPS-KDT button programme switch flashes continuously, maintenance is required. GEZE offers maintenance contracts with the following services: Inspect and adjust the chain. Check the leaf suspension. - Page 12 Post - Warranty period Following the warranty period - GEZE provides a range of Service Contracts to suit individual site requirements. The current BS7036 recommends that powered doors are serviced twice per year - our Service Contracts are therefore based on this important recommendation.
- Page 13 GEZE India Private Ltd. 2630 Taastrup Niederlassung West China MF2 & 3, Guindy Industrial Estate Tel. +45(0)46-323324 Nordsternstraße 65 GEZE Industries (Tianjin) Co., Ltd. Ekkattuthangal Fax +45(0)46-323326 45329 Essen Shuangchenzhong Road Chennai - 600 097 E-Mail: danmark.se@geze.com Tel. +49 (0) 201-83082-0...
