Table of Contents
Notice ..................................................................................................... 2
Cooling notice ................................................................................................................ 2
When edge blending ...................................................................................................... 2
Product information ............................................................................. 3
Packing content .............................................................................................................. 3
Specification ................................................................................................................... 3
Terminals ........................................................................................................................ 4
Remote control .............................................................................................................. 5
Installation ............................................................................................. 6
Lens ................................................................................................................................. 6
Projection table .............................................................................................................. 6
Lens shift range .............................................................................................................. 8
Projector dimension ............................................................................. 10
Lens dimension ...................................................................................... 11
RS232 command ................................................................................... 12
RS232 pin assignment .................................................................................................... 12
1
Advertisement
Table of Contents
Related Manuals for BenQ PX9230
Summary of Contents for BenQ PX9230
-
Page 1: Table Of Contents
Table of Contents Notice ..................... 2 Cooling notice ........................ 2 When edge blending ...................... 2 Product information ................3 Packing content ......................3 Specification ........................3 Terminals ........................4 Remote control ......................5 Installation ..................... 6 Lens ..........................6 Projection table ......................6 Lens shift range ...................... -
Page 2: Notice
Notice Cooling notice y Ventilation Air inlet Air outlet y Caution for installation For proper ventilation of the projector, make sure to leave some space around the projector as shown in the illustration below: • Table 50cm 50cm above above 70cm above • Ceiling • Stacking... -
Page 3: Product Information
Projector with anti-dust cap Remote control Batteries Installation Guide Power cable VGA cable Regulatory Statement Warranty card Specification PX9230 Projection system DLP Single 0.7 XGA DMD Chip Native resolution 1024*768 pixels, 4:3 Brightness 6000 Lumens Light source UHP Lamp Power consumption... -
Page 4: Terminals
Terminals HDMI DVI-D Connection to HDMI source. Connection to DVI source. DISPLAY PORT Connection to DISPLAY PORT source. For connection to RJ45 Cat5/Cat6 Ethernet cable to control the projector through a network. 3D SYNC IN 3D SYNC OUT Connect 3D sync in cable from a computer or an enabled device. Connection to 3D IR sync signal transmitter. -
Page 5: Remote Control
Remote control VOLUME +/- QUICK INSTALL KEYSTONE +/- MUTE ENTER Right Left MENU EXIT Down PICTURE NETWORK INPUT ASPECT AUTO SYNC BLANK FREEZE LAMP MODE OVERSCAN INFO 3D MODE LIGHT CLEAR ID SET Numeric buttons SHUTTER WIRE REMOTE jack y Remote ID setting Press ID SET to set remote ID. -
Page 6: Installation
Installation Lens Model Lens Type Part Number Throw Ratio Lens Shift Vertical: -10%-50% LS2ST3 Wide fix 5J.JDH37.002 0.81 Horizontal: -5%-5% Vertical: -10%-50% LS2ST1 Wide zoom 5J.JDH37.011 1.14-1.347 Horizontal: -5%-5% Vertical: -10%-50% LS2SD2 Standard 5J.JEN37.001 1.6-2 Horizontal: -5%-5% Vertical: -10%-50% LS2LT1 Semi long 5J.JDH37.032 Horizontal: -5%-5% Vertical: -10%-50%... - Page 7 Note: • Ceiling installation must be done by a qualified professional. Contact your dealer for more information. It is not recommended you install the projector yourself. • Only use the projector on a solid, level surface. Serious injury and damage can occur if the projector is dropped. • Do not use the projector in an environment where extreme temperature occurs. The projector must be used at temperatures between 41 degrees Fahrenheit (5 degrees Celsius) and 104 degrees Fahrenheit (40 degrees Celsius).
-
Page 8: Lens Shift Range
Lens shift range y Lens shift adjustable range The adjustable range for lens shift is tabulated below and subject to the conditions listed. Normal projection position Desk-Front Projection Vertical shift Max 0.5V Height of projected image Vertical shift Max 0.1V 0.05H 0.05H Ceiling Mount-Front Projection... - Page 9 BenQ PN Description 5J.JCY10.001 Ceiling mount (CM00G4) y Desktop Installation Screen Center Shift Range 0.05H Note: • The drawings apply to the standard lens only. • Lens Shift feature is not available to LS2ST3 (Fix Lens). This lens should be used for "zero degree"/"no-offset"...
-
Page 10: Projector Dimension
Projector dimension 260.0 (10.23) 240.0 (9.44) AIR INLET 130.0 (5.11) M4x12L AIR EXHAUST 431.0 (16.96) -
Page 11: Lens Dimension
Lens dimension Optional Lens (Wide Fix: LS2ST3) Optional Lens (Wide Zoom: LS2ST1) 316.9 (12.47) 320.5 (12.61) 324.6 (12.77) 392.3 (15.44) Wide Fix Lens Wide Zoom Lens Optional Lens (Standard: LS2SD2) Optional Lens (Semi Long Throw: LS2LT1) 320.5 (12.61) 320.5 (12.61) 327.3 (12.88) 341.9 (13.46) Standard Lens... -
Page 12: Rs232 Command
RS232 command RS232 pin assignment Serial Serial Short with pin8 Short with pin7 Ground Function Type Operation ASCII Power Write Power On <CR>*pow=on#<CR> Write Power off <CR>*pow=off#<CR> Read Power Status <CR>*pow=?#<CR> Source Selection Write COMPUTER/YPbPr <CR>*sour=RGB#<CR> Write COMPUTER 2/YPbPr2 <CR>*sour=RGB2#<CR> Write COMPUTER 3/YPbPr3 <CR>*sour=RGB3#<CR>... - Page 13 Function Type Operation ASCII Picture Setting Write Contrast - <CR>*con=-#<CR> Read Contrast value <CR>*con=?#<CR> Write Brightness + <CR>*bri=+#<CR> Write Brightness - <CR>*bri=-#<CR> Read Brightness value <CR>*bri=?#<CR> Write Color + <CR>*color=+#<CR> Write Color - <CR>*color=-#<CR> Read Color value <CR>*color=?#<CR> Write Sharpness + <CR>*sharp=+#<CR>...
- Page 14 Function Type Operation ASCII Baud Rate Write 2400 <CR>*baud=2400#<CR> Write 4800 <CR>*baud=4800#<CR> Write 9600 <CR>*baud=9600#<CR> Write 14400 <CR>*baud=14400#<CR> Write 19200 <CR>*baud=19200#<CR> Write 38400 <CR>*baud=38400#<CR> Write 57600 <CR>*baud=57600#<CR> Write 115200 <CR>*baud=115200#<CR> Read Current Baud Rate <CR>*baud=?#<CR> Lamp Control Read Lamp Hour <CR>*ltim=?#<CR>...
