- Page 1 PU9730 / PW9620 / PX9710 Digital Projector Installation Guide...
-
Page 2: Table Of Contents
Table of Contents Product information ................3 Lens information ................... 3 Notice (when edge blending) ............... 3 Product information ................4 Lens shift range ..................7 Projector dimension ................9 Clearance around the exhaust vent ............ 10 Lens dimension ..................11 Ceiling mount dimension .............. -
Page 3: Product Information
Product information Type: DLP™ Technology Dimensions (W x H x D): 510 x 230 x 540 mm Weight: 21 kg (46.3 lbs) Specifications PX9710 PW9630 PU9730 DMD size 0.7” 0.65" 0.67” Native resolution XGA (1024 x 768) WXGA (1280 x 800) WUXGA (1920 x 1200) -
Page 4: Product Information
Product information PX9710 Formulas: Definitions: W = Image Width H = Image Height (size) C = Throw distance 4:3 Screen Formulas: W = H x 4/3 H = W x 3/4 Diagonal = W x 5/4 PX9710 Part Number 5J.JAM37.011 5J.JAM37.021 5J.JAM37.001 5J.JAM37.051... - Page 5 PW9620 Formulas: Definitions: W = Image Width H = Image Height (size) C = Throw distance 16:10 Screen Formulas: W = H x 16/10 H = W x 10/16 Screen Diagonal = W x 18.868/16 PW9620 Part Number 5J.JAM37.011 5J.JAM37.021 5J.JAM37.001 5J.JAM37.051 LS1ST3...
- Page 6 PU9730 Formulas: Definitions: W = Image Width H = Image Height (size) C = Throw distance 16:10 Screen Formulas: W = H x 16/10 H = W x 10/16 Screen Diagonal = W x 18.868/16 PU9730 Part Number 5J.JAM37.011 5J.JAM37.021 5J.JAM37.001...
-
Page 7: Lens Shift Range
Lens shift range Lens shift adjustable range The adjustable range for lens shift is tabulated below and subject to the conditions listed. Note: The drawings below apply to the standard lens only. Normal projection position Desk-Front Projection Vertical Shift 0.5V Height of projected image 0.1H 0.1H... -
Page 8: Desktop Installation
Desktop Installation Screen Center Shift Range 0.1H Note: • Lens Shift feature is not available to LS1ST3 (Fix Lens). This lens should be used for "zero degree"/"no-offset" applications. See below: Screen Center 117.4 FOR USE WITH LS1ST3 (FIX LENS) ONLY... -
Page 9: Projector Dimension
Projector dimension 504.7 (19 7/8) 252.5 (10) AIR INLET 428.0 (16 7/8) AIR INLET 213.9 (8 3/8) M4x12L 102.3 (4) 300.0 (11 13/16) AIR EXHAUST AIR EXHAUST AIR EXHAUST... -
Page 10: Clearance Around The Exhaust Vent
Clearance around the exhaust vent For proper ventilation of the projector, make sure to leave some space around the projector as shown in the illustration below: 50cm above 50cm above 70cm above 30cm above Do not place another projector on the top of the projector. -
Page 11: Lens Dimension
Lens dimension Optional Lens (Wide Fix: LS1ST3) New Wide Fix Lens Optional Lens (Wide Zoom: LS1ST1) Wide Zoom Lens... - Page 12 Optional Lens (Ultra Wide: LS1ST2) Ultra Wide Lens Optional Lens (Standard: LS1SD) Standard Lens...
- Page 13 Optional Lens (Semi Long Throw: LS1LT1) Semi Long Throw Lens Optional Lens (Long Throw 1: LS1LT2) Long 1 Lens...
- Page 14 Optional Lens (Long Throw 2: LS1LT3) Long 2 Lens...
-
Page 15: Ceiling Mount Dimension
Ceiling mount dimension Ceiling Mount (Part Number: 5J.JCY10.001) Note: • Mark A: PW9500/PX9600 • Mark B: PU9730/PX9710/PW9620 • Mark C: PX9210/PU9220 ±20°... -
Page 16: Io Panel
IO panel DVI-D HDMI DISPLAY PORT 3D SYNC OUT HDBaseT/LAN COMPUTER-1 MONITOR-OUT R/Pr B/Pb COMPUTER-2 RS-232 TRIGGER WIRED REMOTE • HDBaseT/LAN For connection to RJ45 Cat5/Cat6 Ethernet cable to input uncompressed high-definition video (HD), control signals. • 3D Sync Out Connection to 3D IR sync signal transmitter. -
Page 17: Rs232 Command
RS232 command RS232 pin assignment Serial Serial 1 N.C 6 N.C 2 RXD 7 Short with pin8 3 TXD 8 Short with pin7 4 N.C 9 N.C 5 Ground Function Type Description ASCII Write Power On <CR>*pow=on#<CR> Write Power off <CR>*pow=off#<CR>... - Page 18 Function Type Description ASCII Read Contrast value <CR>*con=?#<CR> Write Brightness + <CR>*bri=+#<CR> Write Brightness - <CR>*bri=-#<CR> Read Brightness value <CR>*bri=?#<CR> Write Color + <CR>*color=+#<CR> Write Color - <CR>*color=-#<CR> Read Color value <CR>*color=?#<CR> Write Sharpness + <CR>*sharp=+#<CR> Write Sharpness - <CR>*sharp=-#<CR> Read Sharpness value <CR>*sharp=?#<CR>...
- Page 19 Function Type Description ASCII Write Projector Position-Front Table <CR>*pp=FT#<CR> Write Projector Position-Rear Table <CR>*pp=RE#<CR> Write Projector Position-Rear Ceiling <CR>*pp=RC#<CR> Write Projector Position-Front Ceiling <CR>*pp=FC#<CR> Write Projector Position-up Front <CR>*pp=UF#<CR> Write Projector Position-down Front <CR>*pp=DF#<CR> Operation Settings Read Projector Position Status <CR>*pp=?#<CR>...
- Page 20 Function Type Description ASCII Read Model Name <CR>*modelname=?#<CR> Write Blank On <CR>*blank=on#<CR> Write Blank Off <CR>*blank=off#<CR> Read Blank Status <CR>*blank=?#<CR> Write Freeze On <CR>*freeze=on#<CR> Write Freeze Off <CR>*freeze=off#<CR> Read Freeze Status <CR>*freeze=?#<CR> Write Menu On <CR>*menu=on#<CR> Write Menu Off <CR>*menu=off#<CR> Miscellaneous Read Menu Status...
- Page 21 Function Type Description ASCII Write 3D Frame packing <CR>*3d=fp#<CR> Write 3D Side by side <CR>*3d=sbs#<CR> Write 3D inverter disable <CR>*3d=da#<CR> Write 3D inverter <CR>*3d=iv#<CR> Read 3D Sync Status <CR>*3d=?#<CR> Write Remote Set <CR>*rrset=0#<CR> Read Remote Set Status <CR>*rrset=?#<CR> Write Trigger on <CR>*trigger=on#<CR>...
