P
OOL
Exceeds Operational Requirements of Model
.
Barrier Codes
Microprocessor Controlled
.
Monitors Entry to Pool and Spa Areas
.
Instant On Or 7 Second Delay Models Available
.
Surface or Flush Mount Models
.
15 Second Adult Shunt Option
.
Low Battery Indicator
.
Optional A or C Form Relay Output Upon Request
.
Built-in Back-up Battery Capable
.
Must Be Hard Wired Using Remote 12 Volt Maximum 500 mA Source or Plug In Power Source.
.
Applied Voltage Must Not Exceed 15 VDC.
The new GRI DOOR ALERT/POOL ALARM was designed as an aid for prevention of an unattended access to a pool/spa
area by a small child. Monitoring all doors or windows with OPEN LOOP magnetic reed switches, the DOOR ALERT/POOL
ALARM will sound an alarm should anyone too small to manage the adult pass thru feature attempt access to the pool/spa
area. For maximum protection all moveable openings should be protected in such a manner by the GRI DOOR ALERT/
POOL ALARM.
The 189N-1, 189N-2, 189N-3 and 189N-4 must be operated with a 12 volt externally supplied DC power source. An
onboard 9-volt battery may be installed, in which case the battery will perform a back-up function should the externally
supplied source fail for any reason. Both power sources have been designed to maintain a minimum sound pressure level
of 85db at 10'. Should the battery voltage drop below 7 volts, a low battery mode will be initiated and the unit will sound
2 beeps approximately every 3 seconds for one to two weeks prior to total battery failure. Battery must be replaced at this
time, and the cause of power failure determined and restored.
It is suggested that some type of surge protection, such as the GRI CS-1 Current Sensor, be used between the power
supply and all GRI Pool Alarms using external power.
NOTE: Unit will function at minimum 5VDC at a very limited sounder volume. This power level is considered total battery
failure.
PART NUMBERS
189N-1
189N-2
189N-3
189N-4
WARNING: THIS IS NOT A LIFE SAVING DEVICE.
GEORGE RISK INDUSTRIES, INC.
G.R.I. PLAZA
KIMBALL, NE 69145
A
LARM
DESCRIPTION
Recessed DoorAlert/Pool Alarm 7 Second Delay - Open Loop
Surface Mount Door Alert/Pool Alarm 7 Second Delay - Open Loop
Recessed Door Alert/Pool Alarm - Instant On - Open Loop
Surface Mount Door Alert/Pool Alarm - Instant On - Open Loop
OPEN LOOP
189N-1/189N-3
Recessed
MADE IN U.S.A.
189N-2/189N-4
Surface Mount
TOLL-FREE 1-800-445-5218
TOLL-FREE 1-800-523-1227
(308) 235-4645
FAX (308) 235-3561
E-MAIL: grisales@megavision.com
WEB SITE: www.grisk.com
