Special Condition Description; Keypad Operation Error Instruction - TECO T-Verter E2 Series Operating Manual

INDICATION CONTENT
Zero Speed
SP0
Stopping
Fail to start
SP1
directly
Keypad
SP2
emergency stop
External
emergency stop
E.S.
b.b. External BASE
BLOCK

Keypad Operation Error Instruction

INDICATION CONTENT
Motor direction
LOC
locked
Er1
Keypad
operation error
Parameter
Er2
setting error

Special Condition Description

DESCRIPTION
When F_11 = 0, F_7= 0 and frequency setting < 1 Hz
When F_11 = 1, F_7<(F_6/100), and frequency setting
<(F_6/100)
1. If the inverter is set to external operation (F_10 = 1) and
direct start is disabled (F_28 =1), the inverter cannot be
started and will flash SP1 when operation switch turned to
ON after applying power (see descriptions of F_28).
2. Direct start is possible when F_28 = 0.
The inverter setup to external operation (F_10=1). If the STOP
key in the keypad is pressed at the middle of operation, the
inverter stops according the setting in F_14 and flash SP2 after
stop. The RUN switch must be turned OFF than ON to restart
the machine.
When the external emergency stop signal is activated through
the multi-function input terminal, the inverter decelerates and
stops. Inverter flashes E.S. after stops. (Refer to instruction for
F_19 for detail).
When the external BASE BLOCK signal is activated through the
multifunction terminal, the inverter stop output immediately and
flash b.b. for indication. (Refer to instruction for F_19 for detail)
POSSIBLE CAUSE
1. Attempt to reverse direction
when F_22 = 1
2. Attempt to set F_22 to 1 when
F_04 = 1
1. Press ▲ or ▼
F_11=1 or under sp1 operation
2. Attempt to modify F_29
3.Attempt to modify parameter that
is not allowed to be modified
during operation
parameter list)
1. F_6≦F_7
keys when
(refer to
46
COUNTERMEASURE
1. Adjust F_22 to 0
2. Adjust F_04 to 0
1. Use ▲ or ▼ keys to
adjust frequency setting
only after F_11=0
2. Do not modify F_29
3. Modify in stop mode
1. F_6 > F_7
