ASSEMBLY AND INSTALLATION
S.R.
SMITH
INSTALLATION AND USE ON RESIDENTIAL INGROUND SWIMMING
POOLS ONLY. THE BIG RIDE IS NEVER TO BE INSTALLED AND USED
ON ABOVEGROUND POOLS, ONGROUND POOLS, HOUSEBOATS, BOAT
DOCKS, FLOATING DOCKS OR PLATFORMS OR OTHER BODIES OF
WATER SUCH AS LAKES, PONDS, RIVERS, ETC.
SRS AUSTRALIA, PTY LTD
12 Enterprise St
Richlands QLD 4077
Australia
Phone 07 3812 2283 • Fax 07 3812 1187
www.srsmith.com/au
06-729
BIG RIDE
INSTRUCTIONS
BIG
RIDE
SLIDES
ARE
MANUFACTURED
S.R. SMITH, LLC
CORPORATE HEADQUARTERS
P.O. Box 400 • 1017 S.W. Berg Parkway
Canby, Oregon 97013
Phone (503) 266 2231 • Fax (503) 266 4334
www.srsmith.com
FOR
USA
NOV16
Advertisement
Table of Contents
Related Manuals for S.R.Smith BIG RIDE
Summary of Contents for S.R.Smith BIG RIDE
- Page 1 SLIDES MANUFACTURED INSTALLATION AND USE ON RESIDENTIAL INGROUND SWIMMING POOLS ONLY. THE BIG RIDE IS NEVER TO BE INSTALLED AND USED ON ABOVEGROUND POOLS, ONGROUND POOLS, HOUSEBOATS, BOAT DOCKS, FLOATING DOCKS OR PLATFORMS OR OTHER BODIES OF WATER SUCH AS LAKES, PONDS, RIVERS, ETC.
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ............................3 INSTALLED BIG RIDE STRUCTURAL & INSTALLATION CHECKLIST ............. 4 MAINTENANCE INSTRUCTIONS ........................ 4 ASSEMBLED BIG RIDE LAYOUT ........................ 5 PARTS LIST ..............................6 PVC LEGS PARTS LIST ..........................6 ASSEMBLY INSTRUCTIONS ........................7 Tools Required ............................7 Slide Preparation ............................ -
Page 3: Introduction
DANGER – FAILURE TO FOLLOW THESE WARNINGS, INSTRUCTIONS, AND THE OWNER’S MANUAL MAY RESULT IN SERIOUS INJURY OR DEATH. THE BIG RIDE IS DESIGNED AND MANUFACTURED FOR INSTALLATION AND USE ON INGROUND SWIMMING POOLS ONLY. DO NOT INSTALL THIS SLIDE ON ABOVE GROUND POOLS, HOUSEBOATS, BOAT DOCKS, FLOATING DOCKS OR PLATFORMS, OR OTHER BODIES OF WATER SUCH AS LAKES, PONDS, RIVERS, ETC. -
Page 4: Installed Big Ride Structural & Installation Checklist
Observe the position of the exit of the slide as shown in FIGURE G, FIGURE H, and FIGURE J on pages 10 and 11. MAINTENANCE INSTRUCTIONS When hosing down the deck, hose your Big Ride to wash away any dust, dirt or other debris, which may have accumulated. Be sure that all connections are secure. Tighten hardware if necessary. -
Page 5: Assembled Big Ride Layout
ASSEMBLED BIG RIDE LAYOUT Ride Length: 17.00’ Centerline Length: 14.00’ Starting Elevation: 5.50’ Slope: 39.29% Open Flume Width: 32.00” Water Flow: 10-45 GPM FIGURE A... -
Page 6: Parts List
PARTS LIST Item Number Description Quantity 3/8” Flat Washer S/S 22 ea. 3/8” x 1 ¾” Hex Head Cap Screw S/S 22 ea. 3/8" Hex Nut S/S 22 ea. 3/8” Lock Washer, Split S/S 22 ea. Sikaflex 291 (10 oz) Gasket Caulk 1 ea. -
Page 7: Assembly Instructions
Remove all three sections of the slide from the carton and place near the desired location for the slide. The Big Ride is equipped with a PVC water jet. It is designed to attach to a 2” PVC pipe. No other components of the water system are included. ... - Page 8 You should place eleven 3/8” x 1 ¾” Hex Head Bolts (2) through the connection of the exit and middle sections to make sure that holes line up properly. The bolts should all face the same direction, with the head of the bolt pointed towards the slide exit. After the bolts are placed through both sections, check to make FIGURE C sure that the slide runway is smooth,...
-
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS Place the assembled BigRide slide on the deck relative to the pool wall. Ensure that the exit flume clears any coping. Slide may be angled slightly providing all dimensions are maintained as noted in the Manufacturer’s Placement Instructions noted in the following section. THE PVC LEGS ARE NOT MEANT AS THE SUPPORT STRUCTURE FOR THE SLIDE. -
Page 10: Manufacturer's Placement Instructions
OPERATION AND TO REDUCE THE RISK OF SERIOUS INJURY. 1. The critical dimensions for placement of the Big Ride are as shown in FIGURE G and FIGURE H. A. The slide exit runway surface shall not exceed twenty inches (20”) above the water surface as shown in FIGURE G. - Page 11 TABLE 1 Board Minimum Clearance Area Pool Type “C” Dimension “W” Dimension 14’ -6” (4420 mm) 5’ -0” (1524 mm) 14’ -6” (4420 mm) 6’ -0” (1829 mm) 16’ -6” (5029 mm) 6’ -0” (1829 mm) 18’ -6” (5639 mm) 7’...
