Summary of Contents for Federal Signal Corporation QuadraFlare DOT
- Page 1 QuadraFlare ® Installation and Service Instructions 25500354 Rev. A1 0420 Para ver este manual en español, Printed in U.S.A. visite www.fedsig.com © Copyright 2016-2020 Federal Signal Corporation...
- Page 2 A copy of this limited warranty can also be obtained by written request to Federal Signal Corporation, 2645 Federal Signal Drive, University Park, IL 60484, email to info@fedsig.com or call +1 708-534-3400.
-
Page 3: Table Of Contents
Contents Safety Message to Installers ............4 Overview of the QuadraFlare............5 Unpacking the QuadraFlare............5 Kit Contents List ................5 Installing the QuadraFlare ............6 Wiring the QuadraFlare ............... 10 Cleaning the QuadraFlare ............11 Safety Message to Operators ............. 12 Getting Technical Support and Service ........ -
Page 4: Safety Message To Installers
Safety Message to Installers Safety Message to Installers People’s lives depend on your proper installation of our products. It is important to read, understand and follow all instructions shipped with the products. Listed below are some other important safety instructions and precautions you should follow: •... -
Page 5: Overview Of The Quadraflare
Kit Contents List Overview of the QuadraFlare The Federal Signal QuadraFlare DOT Warning Light is a self- contained, high intensity, LED light designed for mounting to the exterior of a vehicle. All models are available in a variety of colors and are to be driven by an external flasher. -
Page 6: Installing The Quadraflare
Installing the QuadraFlare Installing the QuadraFlare INSTALL IN RECOMMENDED AREAS: When installing equipment inside airbag equipped vehicles, the installer MUST ensure that the equipment is installed ONLY in areas recommended by the vehicle manufacturer. Failure to observe this warning reduces the effectiveness of the airbag, damage the airbag, or potentially damage or dislodge the equipment, causing serious injury or death to you or others. -
Page 7: Table 3 Hole Patterns
Installing the QuadraFlare Figure 1 Mounting hole locations A/2 (2X) Ø 1.00" B/2 (2X) Table 3 Hole patterns B (2X) Nominal 290A5511-02 size 4 x 3 4.200 2.100 2.375 1.188 6 x 4 5.750 2.875 3.250 1.625 7 x 3 6.562 3.281 2.375... - Page 8 Installing the QuadraFlare Failure to observe these precautions damages the light and void any warranty claims for the light. DRILLING PRECAUTIONS: When drilling holes, check the area you are drilling into to ensure that you do not damage vehicle components while drilling. All drilled holes should be de-burred, and all sharp edges should be smoothed.
-
Page 9: Figure 2 Exploded View
Installing the QuadraFlare Figure 2 Exploded view Legend Mounting Screw, #6 X 2 inch Screws Lens Reflector LED PC Board Assembly Base Assembly Screws (4) Screw Grommet Vehicle Body NOTE: QuadraFlare models have identifiable color-coded sticker dots on the back of the light assembly. The color-coded sticker dots correspond to the LED colors on the PC board. -
Page 10: Wiring The Quadraflare
Wiring the QuadraFlare Wiring the QuadraFlare The Model QuadraFlare Warning Light assembly operates on 12 Vdc. Five 12-inch long lead wires are supplied for making electrical connections to the QuadraFlare Warning Light assembly. Ensure that all wires are properly connected and insulated appropriately. -
Page 11: Cleaning The Quadraflare
Cleaning the QuadraFlare Cleaning the QuadraFlare CRAZING/CRACKING Crazing (fine cracks) of lenses causes reduced effectiveness of the light. Do not use cleaning agents (which cause crazing) such as strong detergents, solvents, or petroleum products. If crazing of the lenses does occur, the reliability of light for emergency signaling purposes may be reduced until the lenses are replaced. -
Page 12: Safety Message To Operators
Safety Message to Operators Safety Message to Operators Peoples’ lives depend on your safe use of our products. Listed below are some important safety instructions and precautions you should follow: • Although your warning system is operating properly, it may not be completely effective. -
Page 13: Getting Technical Support And Service
Getting Technical Support and Service Getting Technical Support and Service For technical support and service, please contact: Federal Signal Corporation Service Department Public Safety Systems Phone: 1-800-433-9132 Email: empserviceinfo@fedsig.com QuadraFlare ® Federal Signal www.fedsig.com... - Page 14 (RMA). Obtain an RMA from a Local Distributor or Manufacturer’s Representative. Provided a brief explanation of the service requested or the nature of the malfunction. Address all communications to the following address. Federal Signal Corporation Service Department 2645 Federal Signal Drive University Park IL 60484-3167 QuadraFlare ®...
-
Page 15: Ordering Replacement Parts
Ordering Replacement Parts Ordering Replacement Parts To order replacement parts, please contact your local dealer/ distributor or: Customer Support Federal Signal Corporation Phone: 1-800-264-3578, 1-708-534-3400 Monday - Friday, 7:00 a.m. to 5:00 p.m. CST http://www.fedsig.com Table 4 Replacement Parts Description... - Page 16 2645 Federal Signal Drive University Park, Illinois 60484 www.fedsig.com Customer Support Police/Fire-EMS: 800-264-3578 • +1 708 534-3400 Work Truck: 800-824-0254 • +1 708 534-3400 Technical Support 800-433-9132 • +1 708 534-3400...
