- Page 1 Model QuadraFlare ® Warning Lights Installation and Service Instructions 25500354 Para ver este manual en español, Rev. A0 0916 visite www.fedsig.com Printed in U.S.A. © Copyright 2016 Federal Signal Corporation...
-
Page 2: Table Of Contents
Contents Safety Message to Installers ........3 Overview of the QuadraFlare........4 Unpacking the QuadraFlare..........4 Kit Contents List ............4 Installing the QuadraFlare ..........5 Wiring the QuadraFlare ..........6 Safety Message to Operators ........7 Cleaning the QuadraFlare ..........8 Getting Technical Support ..........8 Getting Repair Service ..........8 Replacement Parts ............9 Tables Table 1 Wire Functions ..........4... -
Page 3: Safety Message To Installers
Installation and Maintenance Instructions Safety Message to Installers People’s lives depend on your proper installation of our products. It is important to read, understand and follow all instructions shipped with the products. In addition, listed below are some other important safety instructions and precautions you should follow: •... -
Page 4: Overview Of The Quadraflare
Installation and Maintenance Instructions Overview of the QuadraFlare The Federal Signal QuadraFlare DOT Warning Light is a self- contained, high intensity, LED light designed for mounting to the exterior of a vehicle. All models are available in a variety of colors and are to be driven by an external flasher. -
Page 5: Installing The Quadraflare
Installation and Maintenance Instructions Installing the QuadraFlare INSTALL IN RECOMMENDED AREAS: When installing equipment inside airbag equipped vehicles, the installer MUST ensure that the equipment is installed ONLY in areas recommended by the vehicle manufacturer. Failure to observe this warning reduces the effectiveness of the airbag, damage the airbag, or potentially damage or dislodge the equipment, causing serious injury or death to you or others. -
Page 6: Wiring The Quadraflare
Installation and Maintenance Instructions Drill four 1/4" (0.250") mounting holes and a wire routing hole 1" (1.00") at the previously scribed locations. Install the four supplied rubber rivet nuts into the four 1/4" mounting holes. NOTE: When removing the QuadraFlare Warning Lights, inspect the mounting grommets for wear and replace them as needed. -
Page 7: Safety Message To Operators
Installation and Maintenance Instructions Ensure that all wires are properly connected and insulated appropriately. To make electrical connections, proceed as follows: Using 18-gauge (minimum) wire, connect the red (+) lead to the positive power source terminal and the black (–) lead to the negative power source terminal at the flasher. -
Page 8: Cleaning The Quadraflare
Replace any optical components that may have been scratched or crazed during system installation. The use of strong, non-neutral-pH cleaners voids the warranty. Getting Technical Support For technical support, please contact: Federal Signal Corporation Service Department Phone: 1-800-433-9132 Fax: 1-800-343-9706 Email: empserviceinfo@fedsig.com... -
Page 9: Replacement Parts
(RMA). Obtain a RMA from a local Distributor or Manufacturer’s Representative. Provide a brief explanation of the service requested, or the nature of the malfunction. Address all communications and shipments to the following: Federal Signal Corporation Service Department 2645 Federal Signal Dr. University Park, IL 60484-3167 Replacement Parts... -
Page 10: Figure 1 Exploded Assembly View
Installation and Maintenance Instructions Figure 1 Exploded Assembly View LEGEND MOUNTING SCREW, #6 X 2.0", S.S. LENS REFLECTOR LED PC BOARD ASSEMBLY BASE ASSEMBLY SCREWS (4) SCREW GROMMET VEHICLE BODY Model QuadraFlare DOT... -
Page 11: Table 4 Hole Patterns
Installation and Maintenance Instructions Figure 2 Mounting Hole Locations A/2 (2X) Ø 1.00" B/2 (2X) B (2X) Table 4 Hole Patterns 290A5511-02 Nominal size 4 x 3 4.200 2.100 2.375 1.188 6 x 4 5.750 2.875 3.250 1.625 7 x 3 6.562 3.281 2.375... - Page 12 2645 Federal Signal Drive • University Park, IL 60484-3167 Phone: 708-534-3400 • 800-264-3578 • Fax: 800-682-8022 www.fedsig.com...
