- Page 1 PMX1000 & PMX1250 RCD Resistor Replacement Field Service Bulletin 804950 – Revision 2 – July, 2017 Hypertherm Inc. Etna Road, P.O. Box 5010 Hanover, NH 03755 USA 603-643-3441 Tel 603-643-5352 Fax www.hypertherm.com...
- Page 2 See Section 1 of the Operator Manual for more safety precautions. Introduction Purpose Describes necessary steps to replace the RCD resistors (R119 and R120) on the power board of the PMX1000 and PMX1250. Note: This upgrade only applies to power supplies with serial numbers prior to: PMX1000 –...
- Page 3 RCD RESISTOR REPLACEMENT Replace damaged resistors Disconnect power and remove cover from power supply. Discharge capacitors C94 and C98. See photo below. WARNING ELECTRIC SHOCK CAN KILL Use a multi-meter in VDC mode to discharge the capacitors to less than 10VDC before removing the mounting screws. Use wire cutters to remove resistors R119 and R120.
- Page 4 PCB, resistor, large terminal, small terminal, screw Install power supply cover. © Copyright 2017 Hypertherm Inc. All Rights Reserved Hypertherm and Powermax are trademarks of Hypertherm Inc. and may be registered in the United States and/or other countries. Field Service Bulletin...
