- Page 1 XF V-Grip Quick Guide...
- Page 2 XF V-Grip |...
-
Page 3: Table Of Contents
| XF V-Grip Content | XF V-Grip Quick Guide Overview – Buttons, Dials and Parts Supplied content and accessories Mounting the XF V-Grip Adjusting the Quick Release Attaching the Hand Strap Using Buttons and Dials... -
Page 4: Overview - Buttons, Dials And Parts
XF V-Grip | Overview – Buttons, Dials and Parts V-Grip Front Dial V-Grip Shutter Button Electronic Contacts Quick Release Latch Clamp Distance Adjustment Knob... - Page 5 Overview – Buttons, Dials and Parts | XF V-Grip V-Grip Rear User Buttton V-Grip Side Dial Tripod Mount Socket Quick Release Safety Switch Hand Strap Mount...
-
Page 6: Supplied Content And Accessories
XF V-Grip | Supplied content Supplied content and accessories Hand Strap Thread Disc Screwdriver Quick Release Adaptor L-Bracket XF V-Grip Tube... -
Page 7: Mounting The Xf V-Grip
Instructions on next page Warning: Releasing the dual-action quick release of the XF V-Grip while not supporting the XF camera body may result in dropping the camera. The quick release of the XF V-Grip has a dual-action button, which functions as a security lock. - Page 8 XF V-Grip | Mounting the V-Grip Use the supplied screwdriver and Use the supplied disc to remove Remove the rubber cover from the Place the supplied quick release remove the small retaining screw the 1/4” - 3/8” thread adapter electronic contacts by gently...
- Page 9 Mounting the V-Grip | XF V-Grip Use the supplied disc or a coin to Make sure that the quick release Press the V-Grip against the XF To remove the V-Grip, first press securely fasten the quick release on the V-Grip is open. The latch...
-
Page 10: Adjusting The Quick Release
XF V-Grip | Adjusting the Quick Release Adjusting the Quick Release The Quick Release is adjusted to connect correctly and exhibit accurate tension from the factory. Over time, however, the locking mechanism may become slightly loose with repetitive use. You can easily adjust this tension by turning the clamp adjustment knob clockwise with your thumb. - Page 11 Adjusting the Quick Release | XF V-Grip Adjusting for optimal tension of the Quick Release If you want to adjust the V-Grip Quick Release for the optimal tension, or if the Quick Release gives too much resistance when locked, please follow this procedure: Open the Quick Release latch and check that it can reach the line (1) without resistance when closed.
-
Page 12: Attaching The Hand Strap
XF V-Grip | Attaching the Hand Strap Attaching the Hand Strap The supplied hand strap ensures that the XF Camera System can be operated without fear of dropping, and provides extra support to the wrist. You can attach the hand strap to the XF V-Grip whether it is mounted on the XF camera or not. - Page 13 Attaching the Hand Strap | XF V-Grip Ensure the side of the hand strap Fold the tip of the strap as shown, Push the supplied pin into the Hold onto the hand strap with one with the tube and the buckle is...
- Page 14 XF V-Grip | Attaching the Hand Strap Thread the loose end of the strap Thread the strap through the top In order to secure the hand strap as Using scissors, cut the remaining through the top hand strap mount end of the buckle and then pull it...
-
Page 15: Using Buttons And Dials
Using Buttons and Dials | XF V-Grip Using Buttons and Dials The XF V-Grip Shutter Release Button, Front Dial, Rear User Button and Side Dial mirror their functions and the customization that you may have assigned to the dials and buttons on the XF Camera System. You can configure these on the XF Camera System Control Setup menu, accessed by selecting the Rear Key >... - Page 16 Part # 86718401...
