PhaseOne PhotoPhase 85280002 User Manual

Digital camera back for 4"x5" large format cameras
Hide thumbs

Advertisement

D I G I T A L
S T U D
I O
C A M E R A
S Y S T E M
Digital Camera Back for
4"x5" Large Format
Cameras
User's Guide
Edition 3.0
85280002

Advertisement

Table of Contents
loading

  Related Manuals for PhaseOne PhotoPhase 85280002

  Summary of Contents for PhaseOne PhotoPhase 85280002

  • Page 1 D I G I T A L S T U D C A M E R A S Y S T E M Digital Camera Back for 4"x5" Large Format Cameras User’s Guide Edition 3.0 85280002...
  • Page 3: Table Of Contents

    PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide Table of Contents For Your Safety ...2 Section 1: Introduction...3 Section 1.1: How it Works...3 Section 2: Back Panel Description ...5 Section 3: Mounting and Unmounting the Camera Back ...7 Section 3.1: Mounting the Camera Back ...7...
  • Page 4: For Your Safety

    PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide For Your Safety: Read this manual carefully before turning on your system. • If any component of your system becomes wet or damaged, remove power by unplugging the power unit from the wall socket.
  • Page 5: Section 1: Introduction

    PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide Section 1 The PhotoPhase Digital Camera Back The PhotoPhase digital camera back for large format cameras will enable you to use your usual 4" x 5" large format cameras and lenses to take digital photographs in color.
  • Page 6 PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide SCSI Connector Scan Direction Fig.1 Back Panel of the PhotoPhase Plus Protection Legs Dust Cover Handle (in open position) CCD Sensor Scan Area...
  • Page 7: Section 2: Back Panel Description

    PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide image processing settings to perfect your images. Final images are con- verted into the TIFF file format, which is readable by nearly every other image processing and desk top publishing program.
  • Page 8 PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide Fig.2 PhotoPhase camera back mounted on a Sinar camera...
  • Page 9: Section 3: Mounting And Unmounting The Camera Back

    5. Slide the camera back's dust cover all the way up to fully expose the scan area. 6. Be sure to install a Phase One optical filter to reduce infrared light before using the camera back. See Fig.2 for an example of a PhotoPhase camera back fitted to a large format camera.
  • Page 10: Section 4: Care And Cleaning

    PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide Section 4 Care and Cleaning Your PhotoPhase camera back is a sensitive and high precision instru- ment. To keep it working properly, treat it carefully as you would any of your other high quality photography equipment, and take special note of the advice given here.
  • Page 11: Section 4.3: Cleaning The Ccd Sensor

    PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide However, if you notice that your images contain cyan, magenta, or yel- low lines in the direction parallel with the scan movement, then your CCD sensor may be in need of cleaning. In this case, use the following procedure: 1.
  • Page 12: Section 5: Camera Back Specifications

    PhotoPhase Digital Camera Back for Large Format Cameras – User's Guide Section 5 Camera Back Specifications Fits Standard spring-back for all 4"x5" large format cameras Exposed Frame 7 x 10 cm (2.76" x 4") 5000 x 7200 pixels Maximum Print Size at 150 lpi 85 x 121 cm (33"...
