Summary of Contents for PhaseOne H 5
-
Page 1: User Guide
Phase One H 5 User Guide Edition February 2002 Phase One A/S Roskildevej 39 DK-2000 Frederiksberg Denmark +45 36 46 01 11 +45 36 46 02 22 Phase One U.S. 24 Woodbine Ave Northport, New York 11768 +1 631-757-0400 +1 631-757-2217... -
Page 2: Table Of Contents
Sinar, Toyo, Microsoft Windows and Adobe Photoshop area all registered trademarks of their respective companies. The name Phase One H 5, are trademarks of Phase One A/S, Denmark All specifications are subject to change without notice. Phase One takes no responsibility for any loss or damage sustained while using their products. - Page 3 Hardware Set-up Photographic Equipment Set-up Other Photo Equipment LED Indicator Lights 11 Install the Software Installed Items Using the Phase One H 5 12 Software Setup Taking Photographs Selecting Landscape or Portrait Orientation Organizing Images Naming Sessions 13 Editing and Selecting Images...
- Page 4 Table of Contents 15 Camera Info 16 Additional Features Eyedropper 17 Trouble Shooting 18 Strobe Equipment Strobe Equipment Compatibility 19 Photographic Compatibility iiiii 15.1 16.1 16.1 17.1 18.1 18.1 19.1 Table of Contents...
-
Page 5: Macintosh Getting Started
Macintosh Getting Started 1 Macintosh Getting Started The Phase One H 5 has been designed for ease of installation and use. There are just a few easy steps to follow, from unpacking the Phase One H 5 to developing the first shot. -
Page 6: Hardware Set-Up
Macintosh Getting Started Hardware Set-up The Phase One H 5 connects to the computer via an IEEE 1394 connec- tion. This new, extremely fast connection does not have many of the limi- tations of the SCSI technology used in previous digital cameras. Many of the problems related to SCSI such as setting ID numbers, termination, and not being able to “hot-plug”... - Page 7 8) Please note: For the Mamiya RZ the camera must be set to take multiple exposures in order to use the Phase One H 5. The multiple exposure selector (M) is combined with the film back revolve switch (R). Macintosh Getting Started...
-
Page 8: Led Indicators Light
Hasselblad needs to be in the “Film” position. 2) When using the Phase One H 5 on a view camera use the “Two Shot Mode”. This means that the shutter release is activated twice. To shoot an image, release the shutter, reset it, and shoot another frame. -
Page 9: Install The Software
After the computer is restarted, the software that will control the IEEE 1394 card must be installed, as well as the software for the Phase One H 5. We have included one easy-to-use installer that will place all of the necessary software on the computer. Follow these steps to install the software. -
Page 10: Using The Phase One H 5
Using the Phase One H 5 Phase One has made using the Phase One H 5 as close to using film as digital photography can be. The first step to using the Phase One H 5 is to start the application. Double-click the folder called “Capture One Application”... -
Page 11: Software Set-Up
Selecting landscape or portrait orientation The Phase One H 5 can be mounted on a wide range of professional medium format cameras, technical cameras (also referred to as view cam- eras) and other camera systems where image orientation is not automatically detected. -
Page 12: Preview Generation
Software Set-up Files can be moved from the Capture Collection to the Trash, by dragging and dropping them with the mouse. Files can also be named and numbered automatically. Enter a name in the “Session” field of the Capture Collection window. All subsequent captures will now be named accordingly. -
Page 13: Editing And Selecting Images
“Window” menu at the top of the screen. (“Command-2”). The Capture Collection is similar to a contact sheet. It displays thumbnail images of all of the photos taken with the Phase One H 5. Deleting To delete an image, simply click on the thumbnail to select it. A blue box will appear around the image to show that it is selected. -
Page 14: Previewing
If the pointer is in the red area it is overexposed. If it is in the white area it is underexposed. The Phase One H 5 is sensitive to overexposure. Avoid shooting images when the indicator line is in the red area. Here are examples of what... -
Page 15: Develop Specification
Gray Balancing With film photography color bias in light sources, or film emulsion, can be corrected using color correction filters. With the Phase One H 5 we correct color bias by using the gray balance. Unlike many other digital camera systems Phase One has made the gray balance feature easy to... - Page 16 Editing and Selecting Images Simply follow these steps: 1) Open the image to be corrected in the Preview Window. 2) Choose “Gray Balance” from the Camera menu. 3) Click the pointer on an area, which must be neutral gray in the final image.
-
Page 17: Developing Images
Pick Position button. Developing Images Images captured by the Phase One H 5 camera are stored as raw calibrated files. They must by processed by the Capture One before they can be used in any other program. The raw files can be archived and processed at a later time, or processed immediately. -
Page 18: Export Previews
Editing and Selecting Images It is possible to open developed files in Photoshop, or another application, automatically. Open Preferences/Develop File/Attributes to set this option. Export Previews The export preview function allows generation of low resolution previews of the captured images. These previews can be sent to the customer for approval or used in image databases, on web sites or as contact sheets. - Page 19 Editing and Selecting Images Editing and Selecting Images Image Size In the Image Size field allows image resizing in percentages or pixels. 50% is the default size/resolution of a preview. The 'Apply Sharpening' box enables/disables the sharpening settings from the Capture One Software or from third party applications.
-
Page 20: Tools
Tools 5 Tools Many of the tools in the Phase One application act in much the same way as the tools of popular image editing applications such as Adobe Photoshop. Many of these tools actually come from the traditional world;... -
Page 21: Eyedropper
Tools Crop Mask Tool When turned on, the Crop Mask tool will mask the area of the preview image that is outside the selected crop area. Double-clicking this tool allows you to set the color and opacity of the crop mask. This tool is a useful feature when showing images on-screen, as the cropped area is clearly shown. -
Page 22: Tonal Range/Gradation Curves/Film Curve
Tools In general, if the exposure warning is shown over a large area of the selected image, it indicates that the exposure level may need to be adjusted. Highlight areas are more critical than the shadows. Preserve highlight detail by not allowing values greater than 240. Tonal Range/Gradation Curves/Film Curve Clicking on the Tonal Range/Gradation/Film Curve button opens the window to the Tonal Range tool. -
Page 23: Unsharp Mask
The Film Curve tab shows the default film curve and ISO value of the Phase One H 5. Unsharp Mask The name “unsharp mask” (USM) can be misleading. Using this tool actually gives an apparent increase in image sharpness by enhancing the edge differences between pixels of different colors. -
Page 24: Color Management
Tools Color Management The Phase One H 5 is designed to work as part of an ICC color management workflow. The camera, monitor and printer can be specified in the application, and the processed image will be customized for that specific input and output configuration. -
Page 25: Preferences
Preferences 6 Preferences Under the “File” menu is an option called “Preferences”. Select an option from the left-hand side of the window and then set preferences on the right. It is also possible to change the appearance of the user interface. Develop File The Develop File Section controls the naming, file location and other attribution settings. - Page 26 The “Location” tab is used to control where the developed images are stored. The default location for processed images is in the “Images” folder inside the “Phase One H 5” folder on the hard drive. A new folder can also be created or selected.
-
Page 27: Profiles
The software installs basic profiles for the Phase One H 5 camera as well as a generic monitor profile (e.g. Trinitron 1.8) and some RGB color space profiles. -
Page 28: Camera Set-Up
Preferences Preferences Setting up ICC profiles in Adobe Photoshop 6.0 The Capture One Software set up the recommended color Set-up for Adobe photoshop 6.0 automatically. However, if the automatic set-up does not work then install the color setting file called PhaseOne PS60 Defaults.csf. -
Page 29: Camera Info
Camera Information 7 Camera Information The Phase One H 5 has an “info” function that displays important information about the Phase One H 5. This information can be invaluable in troubleshooting problems. If you ever need to contact technical support, be sure to have this information available. To access this data choose “Info...”... -
Page 30: Additional Features
Additional Features 8 Additional Features Demoirize plug-in The Phase One Demoirize plug-in for Adobe Photoshop allows the removal of moiré patterns from images by means of three different filtering modes: Advanced, Unicolor Textiles and Skin and Hair. The plug-in is enclosed on the CD-ROM and will be placed in Adobe Photoshop’s plug-ins folder when installing Capture One Software. - Page 31 Additional Features Advanced mode Advanced mode is a new filter tool. It is also the default mode of the Demoirize plug-in. In advanced mode the filter estimates colors by means of the Quality/Speed slider and the Pattern Size slider. Often the color moiré is visible by multiple red/green or blue/yellow areas of discoloration.
-
Page 32: Trouble Shooting
Trouble Shooting 9 Trouble Shooting If technical problems are experienced when working with the Phase One H 5 it may be necessary to contact Phase One’s Technical Support department. Phase One recommends that you do a screen dump of your system configuration. -
Page 33: Windows Getting Started
10 Windows Getting Started The Phase One H 5 has been designed for ease of installation and use. There are just a few easy steps to follow, from unpacking the Phase One H 5 to developing the first shot. Connect hardware, install software... -
Page 34: Photographic Equipment Set-Up
10.2 Photographic Equipment Set-up In addition to setting up the computer, the camera must be prepared to work with the Phase One H 5. This involves a few simple steps: 1) A Ground Glass Mask is included. This must be installed in the viewfinder to ensure correct framing. - Page 35 Hasselblad needs to be in the “Film” position. 2) When using the Phase One H 5 on a view camera use the “Two Shot Mode”. This means that the shutter release is activated twice. To shoot an image, release the shutter, reset it, and shoot again.
-
Page 36: Led Indicator Lights
Windows Getting Started LED Indicators Lights On the back of the Phase One H 5 are two sets of LED indicator lights. A red and green light on the left and a red and green light on the right. The left and right pairs are identical and should always display the same thing. -
Page 37: Install The Software
After the computer is restarted, the software that will control the IEEE 1394 card must be installed, as well as the software for the Phase One H 5. We have included one easy-to-use installer that will place all of the necessary software on the computer. -
Page 38: Installed Items
11.2 Using the Phase One H 5 Phase One has made using the Phase One H 5 as close to using film as digital photography can be. The first step to using the camera back is to start the application. Double-click the Capture One short-cut. -
Page 39: Software Setup
Tools or Preferences section of this manual. Taking Photographs The Phase One H 5 is designed for ease of use and high performance. First time digital photographers, as well as experienced digital photographers, can immediately begin taking images of excellent quality. -
Page 40: Naming Sessions
Software Set-up Naming Sessions The Session Creator is a feature that enables you to name the capture folder, and associate this capture folder with a dedicated develop folder, in one simple operation. 12.2 All developed capture files are stored in a sub folder called Develops (C:\Program Files\Capture One Basic\Scuba\Develops), which is automatically created by checking the box Develop capture in the Session Creator dialogue box. -
Page 41: Editing And Selecting Images
13 Editing and Selecting Images The Phase One software main window is divided into three sections that make it functional and easy to use. The sections are: Capture Collection The Capture Collection is located on the left side of the interface screen and will show a small thumbnail of the images in the currently selected capture directory. -
Page 42: Function Window/Function Tabs
Editing and Selecting Images Function Window/Function Tabs On the right hand side of the main interface is the Function Window. The options in this area change depending on which of the function tabs is selected. The tabs are: Preview, Gray Balance, Exposure, Focus and Develop. -
Page 43: Function Tabs And Window
Editing and Selecting Images Function Tabs and Window The Function Tabs add features to the Phase One H 5 software without adding the clutter of multiple dialog boxes. Click on a tab to change the contents of the Function window and to enhance and evaluate the image before developing. -
Page 44: Gray Balance Tab
Gray Balance Tab When shooting film under various light sources, such as flourescent or tungsten lighting, compensation for color cast is made by using filters. With the Phase One H 5 compensation is made by changing the gray balance. 13.6... -
Page 45: Exposure Tab
0 to 255. A completely black pixel is represented as 0, a completely white pixel as 255. Again, it is important not to overexpose an image when using the Phase One H 5; if you see any of the Red, Green or Blue (RGB) values approaching overexposure (a value of 255) you need to adjust the exposure level. - Page 46 Editing and Selecting Images To control the brightness and contrast of the image two standard tools are available: Levels and Curves. Levels The first part of the Exposure Tab is the Levels control. This is a standard levels box similar to that of Adobe Photoshop. To make an adjustment drag the black or white slider left or right to either darken the shadows or lighten the highlight.
-
Page 47: Focus Tab
To evaluate the focus of an image simply click on the area of the image (in the main Preview Window) and the Phase One H 5 software will zoom in to a 1:1 final image of that part of the photo. Zoom in more than 100% by using the slider below the Focus Window. -
Page 48: Menu Settings
0 to 50. A third option found in many imaging programs, Radius, is fixed in the Phase One program at about 1 pixel. As the settings are adjusted they are updated in the preview image. This feature can be turned off by un-checking the “Preview Settings”... - Page 49 Editing and Selecting Images Copy from active capture You select the capture file you wish to copy from - the so-called reference, then you go to the Workflow pull-down menu and choose 'Copy settings from.../Active capture'. This feature is especially useful when shooting product set-ups where the lighting is fixed and where composition layout and cropping can be determined prior to the actual shooting.
-
Page 50: Developing
Capture Collection. Developing Images captured by the Phase One H 5 digital camera back are stored as raw calibrated files. They must by processed by the Capture One application before they can be used in any other program. The raw files can be archived and processed at a later time, or processed immediately. - Page 51 Editing and Selecting Images To process an image, it first must be opened in the preview window. It may help to think of the development stage as similar to print making in the darkroom. After loading the image into the Preview Window the first step will be to gray balance and crop the image.
-
Page 52: Export Previews
Editing and Selecting Images Browse Develop Folder Clicking on this button will open the currently selected develop folder. At the bottom of the Develop tab is a status bar that shows a development progress bar and the percentage of the image that has been developed and the approximate time left to develop the image. - Page 53 Editing and Selecting Images Destination folder The Destination Folder is where you organize the workflow. You choose your own destination folder. If no destination folder is selected then a default folder called 'Exported Previews' is created inside the capture collection folder. Name postfix In this field you can add unique image names/ID.
-
Page 54: Tools
14 Tools Many of the tools in the Phase One application act in much the same way as the tools of popular image editing applications such as Adobe Photoshop. Many of these tools actually come from the traditional world; the cropping tool is the first example of this, mimicking the cropping “L’s”... -
Page 55: Exposure Warning
The preview is shown in grayscale. This does not affect the developed file. Soft Proofing and Color Management The Phase One H 5 is designed to work as part of an ICC color management workflow. The camera, monitor and printer are specified in the Capture One application, and the processed image will be customized for that specific input and output configuration. -
Page 56: Simulate Sharpening Settings
A brief guide to preference settings is provided here: Camera Profile Select the correct profile: Phase One H 5 product Flash, Phase One H 5 Tungsten, Phase One H 5 Outdoor Daylight or Phase One H 5 Portrait. Destination (working space) Select between the available profiles. -
Page 57: Unsharp Mask
Tools Unsharp Mask The name “unsharp mask” (USM) can be misleading. Using this tool actually gives an apparent increase in image sharpness by enhancing the edge differences between pixels of different colors. When applied, the software evaluates the contrast differences between pixels and either enhances the difference or not, based on setting made in the preferences. -
Page 58: Camera Info
Camera Info 15 Camera Info The Phase One H 5 has an “info” function that displays important information about the connected camera back. This information can be invaluable in troubleshooting problems. If you ever need to contact technical support, be sure to have this information available. -
Page 59: Additional Features
Additional Features 16 Additional Features Demoirize Plug-in The Phase One Demoirize plug-in for Adobe Photoshop allows you to remove moiré patterns from your images by means of three different filtering modes: Advanced, Unicolor textiles as well as Skin and Hair. - Page 60 Additional Features Quality/Speed When large areas of moiré stripes and bands are present the Quality/ Speed slider should be set towards Quality, at the cost of Speed. Use the Quality setting when details smaller that the selected pattern size should be less affected by the filtering. Using advanced mode on skin and hair For skin and hair surfaces the optimal settings for the advanced filter would be to position the Quality/Speed slider at Speed and the Pattern...
-
Page 61: Trouble Shooting
Print Screen to generate a screen dump of the current settings. Then open and save the screen dump in any image editing software. Fax or e-mail your Camera Info and the System Profile to Phase One’s Technical Support department. 17.1... -
Page 62: Strobe Equipment
ISO standard 10330. However, since some strobe equipment does not comply with this standard, Phase One has expanded the LightPhase /Phase One H 20 tolerances past those of the ISO standard. If your strobe system does not comply with the above- mentioned ISO standard please use the tolerances in the below tables as reference. - Page 63 Strobe Equipment Strobe compatibility with all Phase One H 5 (S/N #: BR, BS, BT) Strobe Systems Balcar P4 pack Bowens Estime 3000 Bowens Estime 3000AMF Bowens Estime 3000ASC Bowens Esprit 2 125 Bowens Esprit 2 250 Bowens Esprit 2 500...
- Page 64 Warning: Norman 2000PS produces strong voltage should never be used with Phase One H 5. * = More tests need to be carried out - if in doubt please contact Phase One or send the above trigger specifications to the strobe manufacturer 18.4 Strobe Equipment 18.5...
-
Page 65: Photographic Compatibility
The below table shows the photographic equipment that Phase One recommends (+) or does not recommend (-) you use together with the Phase One H 5 for Hasselblad and Mamiya RZ67 Pro II (the latter requires an adaptor), Phase One H 5 for Mamiya 645AF and Phase One H 5 for CONTAX 645. - Page 66 250mm f/4.5 APO 350mm f/5.6 APO 500mm f/8 100-200mm f/5.2 Zoom 37mm f/4.5 Fisheye 75mm f/4.5W Shift 140mm f/4.5 Macro Phase One H 5 for Mamiya 645AF (S/N #: BT) Camera Systems Status Mamiya 645AF Lenses Status Mamiya 645AF 19.3...
- Page 67 Toyo 4x5 > f-90mm Arca Swiss 4x5 > f-90mm Linhof 4x5 > f-90mm Cambo 4x5 > f-90mm Electronic Shutters Horseman ISS-G2 Shutter Phase One H 5 for CONTAX 645 (S/N #: BS) Camera Systems CONTAX 645 Lenses CONTAX 645 Lenses via Adaptors...
- Page 68 Part No: 8001700...
