Early Childhood Resources ELR-0631 Manual

Combo Fold & Lock
(Medium Storage and
20-Tray Cabinet)
Model No. ELR-0631
Mount Laurel,NJ 08054 USA
www.ecr4kids.com
G2
A2
B
F
F
F
F
A1 E
C2
C1
C2
D
Left Unit
A1
Left Side Panel
A2
Right Side Panel
L
B
Top Shelf
G2
C1
Middle Shelf(1)
C2
Middle Shelf(2)
D
Bottom Shelf
E
Back Panel(5)
F
Divider(4)
BEFORE ASSEMBLING,
Right Unit
MAKE SURE THERE
G1
ARE NO
Right Side Panel
MISSING PARTS.
G2
Left Side Panel
H
Top Shelf
!
WARNING:
I
Middle Shelf
J
Divider(3)
K
Bottom Shelf
- Adult Assembly Required. Two
L
Back Panel(2)
adults recommended.
Hardware
- Contains small parts, sharp points
M
Metal Dowel(14)
and edges.
N
Large Hex Screw(38)
O
Wheel Caster(8)
- Do not stand, sit, kneel, climb, lean
or pull on unit for support.
P
Caster Screw(32)
- Never leave children unattended.
Q
Cam(14)
- Do not place unit near high heat or
S
Hex Key Tool
moisture.
T
Piano Hinge
- Adult Supervision Recommended.
U
Post(12)
V
Post Screw(12)
W
Safety Hasp with
7 Screws
1
Attach the Dividers to the Top Shelf
H
J
L
I
J G1
J
K
E
A1
TIP！
DO NOT FULLY
TIGHTEN SCREWS
UNTIL ALL SCREWS
HAVE BEEN LOOSELY
POSITIONED。 1A. Place the Top Shelf(B) top-down on a carpet or protected surface.
Insert 8 Metal Dowels(M) into the plastic plugs located underneath
the Top Shelf(B). Tighten with a Phillips Head Screwdriver.
1B. Insert 2 Cams(Q) into the large holes in each of the Dividers(F).
Make sure the arrows on Cams(Q) point toward the holes in the closest
edge.
1C. Position the Top Panel(B) so the attached Metal Dowels(M) enter the
holes in the top edge of the Dividers(F). Turn Cams(Q) with a Phillips
Head Screwdriver until locked onto the Metal Dowels(M).
2
Insert the Back Panels
2. Slide the Back Panels(E) into the grooves between the Dividers(F)
until fully inserted into the slot as shown.
B
M
M
Ｘ８
F
Q
F
F
F
M
B
E
E
E
E
E
F
F
F
F
B
3
Insert the Middle Shelves
Ｘ８
C2
C1
C2
F
B
F
E
F
E
E
4
Attach the Divider Section to
the Base
F
F
F
F
5
Attach the Wheel Casters
5. Beginning with the holes on the inside of the Wheel Caster(O) mount
plate, attach the 4 Wheel Casters(O) to the Base(D) using 16 Caster
Screws(P). Tighten with a Phillips Screwdriver.
P
O
Ｘ１６
P
D
C2
C1
C2
F
B
3A. Two Adults Suggested:
Carefully lay the unit down
on its back. Insert a Middle
Shelf(C2) into the bottom slots
on the Dividers(F) as shown
until fully inserted.
3B. Insert a Middle Shelf(C1)
into the middle slots on the
F E
Dividers(F) as shown until
E
fully inserted.
3C. Insert a Middle Shelf(C2)
into the top slots on the
Dividers(F) as shown until
fully inserted.
4A. Two Adults
N
Suggested:
Carefully turn the
Ｘ８
unit upside down to
N
D
rest on Top Shelf(B).
4B. Attach the Base
to the Divider
C2
Section(F,E,C1,C2)
C1 using 8 Large Hex
Screws(N). Tighten
C2
with the Hex Key
B
Tool(S).
Caster
Screw
Mount
Ｘ４
O
Plate
Attach
First
Version: ELR-0631.D.2010.01.03
