Early Childhood Resources ELR-0627 Manual

High Storage Cabinet
(8-Compartment)
Model#: ELR-0627
Mount Laurel,NJ 08054 USA
www.ecr4kids.com
BEFORE ASSEMBLING,
MAKE SURE THERE
ARE NO
MISSING PARTS.
TIGHTEN SCREWS
UNTIL ALL SCREWS
HAVE BEEN LOOSELY
!
Adult Assembly Required.
adults recommended.
- Contains small parts, sharp points
Large Hex Screw(26)
and edges.
- Do not stand, sit, kneel, climb, lean
or pull on unit for support.
- Never leave children unattended.
- Do not place unit near high heat or
moisture.
Caster Screw(16)
- Adult Supervision Recommended.
NOTE:
A Phillips Head Screwdriver
will be needed for
assembly (not included)
1
X4
I
TIP！
DO NOT FULLY 1C. Insert 4 Metal Dowels(H) into the
plastic plugs located underneath the
Center Bottom Shelf(D). Tighten with
a Phillips Screwdriver. Attach the
Divider(G) to the Center Bottom
POSITIONED。
Shelf(D) using 2 Large Hex Screws(I).
Tighten with the Allen Wrench(J) .
WARNING:
2
Two
2A. Insert 2 Cams (M) into the Divider(G). Make sure arrows on
Cams (M) point toward holes in the closest edge.
2B. Position Center Bottom Shelf(D) so the attached Metal Dowels(H)
enter the holes in the top edges of the 2 lower Dividers(G) as shown.
Turn Cams(M) with a Phillips Head Screwdriver until locked onto the
Metal Dowels(H).
Attach the Dividers to the
Bottom and Center Shelves
X4
M
1A. Insert 4 Cams(M) into large holes on
the inside of a 2 Dividers(G). Make sure
arrows on Cams(M) point toward holes in
the closest edge.
1B. Attach the 2 Dividers(G) to the Bottom
Shelf(E) using 4 Large Hex Screws(I).
Tighten with the Allen Wrench(J) .
X2 X4 X2 X4
I I H H
Attach the Center Bottom Shelf
3
Assemble the Top Section
3A. Attach the 2 Dividers(G) to
the Center Top Shelf(C) using
4 Large Hex Screws(I). Tighten
with the Allen Wrench(J).
3B. Insert 4 Metal Dowels(H) into
the plastic plugs located under
Top Shelf(B). Tighten with the
Phillips Head Screwdriver.
3C. Insert 4 Cams(M)
into the 2 Dividers(G).
Make sure the arrows
on Cams(M) point
toward the holes in
the closest edge.
3D. Position Top
Shelf(B) so the
3C,3D
attached Metal
Dowels(H) enter
the holes in the top
edge of the Dividers(G) as shown. Turn the Cams(M) with a Phillips Head
Screwdriver until locked onto the Metal Dowels(H).
4
Attach the Top and Bottom Sections
4A. Two Adults Suggested: On a cartpet or protected surface, carefully
lay the assembled components on their backs, facing upward.
4B. Insert 2 Metal Dowels(H) into the plastic plugs located under the
Center Top Shelf(C). Tighten with the Phillips Head Screwdriver.
4C. Insert 2 Cams(M) into
the last Divider(G). Make
sure arrows on Cams(M)
point toward the holes in
the closest edge.
X2
M
4D. Position the Top
Divider Section(B,G,C)
so the attached Metal
Dowels(H) enter holes
in the top edge of the
Divider(G) that is
attached to the Bottom
Divider Section(G,D,E)
as shown.
Version: ELR-0627.D.2010.01.03
X4 X4
I
