Early Childhood Resources ELR-0636 Manual

25-Tray Storage Cabinet
Model No. ELR-0636
Mount Laurel,NJ 08054 USA
www.ecr4kids.com
A2
A1 B
C2
B
C1
C2
C2
F
D
A2
F
D F
F
BEFORE ASSEMBLING,
MAKE SURE THERE
ARE NO
MISSING PARTS.
PARTS LIST
A1
Left Side Panel
A2
!
Right Side Panel
B
Top Shelf
C1
- Adult Assembly Required. Two
Middle Shelf(1)
C2
adults recommended.
Middle Shelf(3)
- Contains small parts, sharp points
D
Bottom Shelf
and edges.
E
Back Panel(5)
- Do not stand, sit, kneel, climb, lean
F
Divider(4)
or pull on unit for support.
G
- Never leave children unattended.
Large Hex Screw(20)
- Do not place unit near high heat or
H
Metal Dowels(8)
moisture.
I
- Adult Supervision Recommended.
Hex Key Tool
J
Wheel Casters(4)
K
Caster Screws(16)
L
Cams(8)
1
E
Ｘ８
L
A1
TIP！
DO NOT FULLY
TIGHTEN SCREWS
1A. Place the Top Shelf(B) top-down on a carpet or protected surface.
UNTIL ALL SCREWS
HAVE BEEN LOOSELY Insert 8 Metal Dowels(H) into the plastic plugs located underneath
POSITIONED。
the Top Shelf(B). Tighten with a Phillips Head Screwdriver.
1B. Insert 2 Cams(L) into the large holes in each of the Dividers(F).
WARNING:
Make sure the arrows on Cams(L) point toward the holes in the closest
edge.
1C. Position the Dividers(F) so Metal Dowels(H) attached to Top Panel(B)
enter the holes in the top edge. Turn Cams(L) with a Phillips Screwdriver
until locked onto the Metal Dowels(H).
2
2. Slide the Back Panels(E) into the grooves between the Dividers(F)
until fully inserted into the slot as shown.
Attach the Dividers to the Top Shelf
B
H
F
F
F
F
B
Insert the Back Panels
E
E
E
E
E
F
F
F
F
B
3
Insert the Middle Shelves
C2
C2
C1
E F
C2
Ｘ８
H
B
4
Attach the Divider Section to
L
the Base
G
F
F
F
F
5
Attach the Wheel Casters
5. Beginning with the holes on the inside of the Wheel Caster(J) mount
plate (opposite the kickplate on Base(D)), attach the 4 Wheel Casters(J)
using 16 Caster Screws(K). Tighten with a Phillips Screwdriver.
K
J
D
C2
C2
C1
C2
F
B
Version: ELR-0636.D.2010.01.03
3A. Insert a Middle
Shelf(C2) as shown
onto the Dividers(F)
until fully inserted.
3B. Insert a Middle
Shelf(C1) as shown
onto the Dividers(F)
at the center slots
until fully inserted.
3C. Insert 2 Middle
Shelves(C2) onto the
Dividers(F) as shown
until fully inserted.
4. Attach the Base
to the Divider
Section(F,E,C1,C2)
using 8 Large Hex
D
Screws(G). Tighten
Ｘ８
with the Hex Key
E
G
Tool(I).
C2
C2
C1
C2
B
Caster
Ｘ１６ Ｘ４
J Screw
K
Mount
Plate
Attach
First
