Early Childhood Resources ELR-0634 Manual

5-Section Coat Locker
with Bench
Model # ELR-0634
Mount Laurel,NJ 08054 USA
www.ecr4kids.com
TIGHTEN SCREWS
B
UNTIL ALL SCREWS
HAVE BEEN LOOSELY
C
A2
F
F
F
F
G
G
G E
G
A1
A2
A1 BEFORE ASSEMBLING,
Left Side Panel
MAKE SURE THERE
A2
Right Side Panel
B
Top Shelf
C
Upper Center Shelf
D
Lower Center Shelf
!
E
Bottom Shelf
F
Upper Divider(4)
G
Lower Divider(4)
- Adult Assembly Required. Two
H
Lower Back
adults recommended.
I
Upper Back(5)
- Contains small parts, sharp points
J
Metal Dowels(16)
and edges.
K
Round Hex Head
Screw(24)
- Do not stand, sit, kneel, climb, lean
L
Flat Hex Head
or pull on unit for support.
Screw(8)
- Never leave children unattended.
M
Hex Key Tool
- Do not place unit near high heat or
N
Hooks(10)
moisture.
- Adult Supervision Recommended.
O
Posts(12)
P
Post Screws(12)
Q
Cams(16)
NOTE:
A Phillips Head Screwdriver
will be needed for
assembly (not included)
1
TIP！
DO NOT FULLY
POSITIONED。
B
I
I
1A. Attach 4 Lower Dividers(G) to the Base(E) using 8 Round Hex Head
I
Screws(K), using 2 in each. Tighten with the Hex Key Tool(L).
I
2 Attach the Upper Dividers to the
I
Lower Center Shelf
H
ARE NO
MISSING PARTS.
WARNING:
2A. Two Adults Suggested: On a carpet, or protected surface, attach
Upper Dividers(F) to the Lower Center Shelf(D) using 8 Flat Hex-Head
Screws(L), using 2 in each. Tighten with the Hex Key Tool(M).
2B. Insert 8 Metal Dowels(J) into the plastic plugs located underneath
Lower Center Shelf(D). Tighten with a Phillips Head Screwdriver.
3
3A. Lay the assembled Base(E,G) on its side. Insert 8 Cams(Q) into the
large holes located in the 4 Lower Dividers(G), using 2 in each. Make
sure the arrows on Cams(Q) point toward the holes in the closest ends.
3B. Two Adults Suggested: Position the assembled Upper Section(D,F)
so the Metal Dowels(J) attached to Lower Center Shelf(D) enter the holes
in the top edges of the Lower Dividers(G) as shown.
Attach Lower Dividers to
Bottom Panel
G
G
G
G
E
X8 X8
Q K
X8 X8
L
Attach the Top Section to the
Bottom Section
F
F
F
F
4
Attach the Upper Center Shelf
and Back Panels
G
G
D
F
F
F C
J
F I
I
I
I
F
F
F
Version: ELR-0634.D.2010.01.02
3C. Turn Cams(Q)
with a Phillips Head
G
Screwdriver until
locked onto the Metal
Dowels(J).
G
G
G
D
Q
J
4A. Insert Upper Center
Shelf(C) onto the slots in
E
the 4 Upper Dividers(F) as
G
shown, until fully engaged.
G
4B. Two Adults
Suggested: Carefully
stand the unit upright.
4C. Slide the 5 Upper
Backs(I) into the grooves
between the Upper
Dividers(F) and into the
groove in the Lower Middle
Shelf(D) until fully inserted.
4D. Slide the Lower
Back(H) into the grooves
between Lower Middle
I
Shelf(D) and Bottom
Shelf(E) until fully inserted.
TIP:
C
- If the Back Panel does
not slide easily into the
F
grooves, wiggle the Back
while pushing the panel
into the slot.
- You may also turn the
rear Cams on the shelf
D
above or below to unlock,
H
push the Back until fully
inserted into the slot, then
E
turn Cams to the locked
position again.
