Vertical Positioning of Hinges
Although Euro-style concealed hinges allow for vertical
adjustment, the mounting locations on the door and the face
frames must line up. The easiest way to accomplish this is to
mark aligning horizontal centerlines on both the door and the
cabinet face frame. You need to consider the amount of the
door's overlay or inset when calculating the centerline
positions for the door.
1. For the top hinge, measure down from the top of the cabinet
opening to the desired mounting location (typically 2"-3") and
use a combination square to mark the horizontal centerline on
the inside edge of the face frame. (For the bottom hinge,
measure up from the bottom of the cabinet opening.)
Note: Be sure your hinge positions will provide adequate
clearance for any pullouts.
2. To determine the centerline location on the door, start with
the distance you measured in Step 1 and add the amount
the door will overlap at that edge.
3. Use the values calculated for the top and bottom hinge
locations in Step 2 and mark the horizontal centerlines on
the back of the door. Compare the distance between the
lines on the face frame with the distance between the
lines on the door to verify.
Installing Hinges
1. Refer to the Door Diagram to mark drilling locations for the
hinge cup holes and mounting screw holes on the door.
2. Using a 35mm Forstner bit, drill a hole 11mm deep for
the hinge cup, taking care to keep the bit as square as
possible to the door.
Note: For fast, easy and accurate location and drilling of hinge
cup holes, we recommend using the JIG IT Deluxe Concealed
Hinge Drilling System (53420, sold separately) along with
a Rockler 35mm Long-Shank Forstner Bit (10117, sold
separately). For those using a drill press, a dedicated JIG IT
setup block is available (53438, sold separately).
3. Drill pilot holes for the screws, taking care not to drill all
the way through the door.
4. Position the hinge cup in the hole and use the included
screws to secure in place.
5. Repeat Steps 2-4 at other hinge location(s).
Hinge
Finish
Tab
Blum 105°
Nickel 3mm
Compact
Cup
Cup
Minimum Door
Diameter
Depth
Thickness
35mm
11mm
16mm (.63")
Blum 105° 1
1
4
Frame Compact Hinge Instructions
Installing Hinge to Face Frame
1. Refer to the Face Frame Diagram to mark the drilling
locations for the hinge mounting screws.
2. Drill pilot holes for the mounting screws.
Note: For fast, easy and accurate location and drilling of
mounting plate pilot holes, we recommend using the JIG IT
Hinge Plate Template C (58009, sold separately) along
with a Rockler/Insty-Drive #8 Self-Centering Bit (68998,
sold separately).
3. Hold the door up to the face frame and use the included
pan-head screws to secure the hinges to the face frame.
Check Rockler.com for updates. If you have further questions, please
contact our Technical Support Department at 1-800-260-9663
or support@rockler.com
Maximum Door
Adjustments
Thickness
19mm (.75")
2 cam, 1 slot
" Overlay Face
Clip-on
Gap
Mounting
5mm
No
31329
Minimum
Reveal
7mm
1
