- Page 1 ⁄ " Fixed Louver Shutter Jig Instructions Effective November 2018 Review full manual instructions prior to use for important safety information. Always check Rockler.com to confirm that you are using the most recent manual version for your product.
- Page 2 Instructions and safety warnings for your product (see the • Keep children and bystanders away from the tool Instructions link on the product page at Rockler.com). operating area; • Do NOT use power tools in explosive environments, or in >...
- Page 3 PRODUCT SPECIFIC SAFETY WARNINGS > To avoid serious injury, keep hands and fingers away from spinning router bit. Maintain awareness of the bit at all times. > Use only a plunge router with this jig. Use of a fixed-base > Be careful when clamping softwoods to avoid crushing router is likely to result in damage to the jig.
- Page 4 • Window opening should be nearly square Window • Solid wood jamb needed • Butt hinge application ⁄ " ⁄ " Stile Rail Wall with or without trim Fig. 1 - Inside mount, no frame • Mounting for window openings that are not square ⁄...
- Page 5 Leave 1/16" gaps where hinges are mounted and 1/8" gaps between panels 5. Enter these measurements in the Shutter Design Wizard at Rockler.com to create your Bill of Materials and Dimensioned Plans specific to your shutters. Shutter Design Options 1.
- Page 6 Routing Stiles THESE WARNINGS PERTAIN TO ALL REMAINING STEPS: Left Stile back side > To avoid serious injury, keep hands and fingers away from spinning router bit. Maintain awareness of the bit at all times. > Use only a plunge router with this jig. Use of a fixed-base router is likely to result in damage to the jig.
- Page 7 9. When all parts are together, clamp the frame tight and check for square. Check Rockler.com for updates. If you have further questions, please contact our Technical Support Department at 1-800-260-9663 or support@rockler.com Fig. 6...
- Page 8 49470 Distributed by Rockler Companies, Inc. Rev 11/18 Medina, MN 55340...
