Blum 110° BLUMotion Variable Overlay
Face Frame Compact Hinge Instructions
Effective August 2018
Finish
Nickel
Maximum Door
Thickness
19mm (.75")
Review full manual instructions prior to use for important safety information.
Always check Rockler.com to confirm that you are using the most recent
Tab
Diameter
3mm
Adjustments
2-way
manual version for your product.
Cup
Cup Depth
35mm
11mm
Clip-on
Gap
Mounting
5mm
Minimum Door
Thickness
16mm (.63")
Minimum
Reveal
No
7mm
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rockler Blum BLUMotion GRP31256 1
Summary of Contents for Rockler Blum BLUMotion GRP31256 1
- Page 1 16mm (.63") Maximum Door Clip-on Minimum Adjustments Thickness Mounting Reveal 19mm (.75") 2-way Review full manual instructions prior to use for important safety information. Always check Rockler.com to confirm that you are using the most recent manual version for your product.
-
Page 2: General Safety Warnings
(see the precautions outlined in this manual prior to use. Instructions link on the product page at Rockler.com). > Follow all standard shop safety > Before using another tool with this product, practices, including: always read, understand and follow the •... - Page 3 SAFETY WARNING KEY Danger indicates a hazardous situation that, if not avoided, will result in death or serious injury. Warning indicates a hazardous situation that, if not avoided, could result in death or serious injury. Caution indicates a hazardous situation that, if not avoided, may result in minor or moderate injury or property damage.
- Page 4 Inside Edge Front of of Door Face Frame 20.5 Center Mark Centerline Variable All measurements are in millimeters Door Diagram Face Frame Diagram Vertical Positioning of Hinges Although Euro-style concealed hinges allow and use a combination square to mark the for vertical adjustment, the mounting locations horizontal centerline on the inside edge of on the door and the face frames must line up.
- Page 5 Cabinet Face Frame Reveal Hinge Cup Door Cup Depth Diagram Installing Hinges 1. Refer to the Door Diagram to mark drilling 4. Position the hinge cup in the hole and use locations for the hinge cup holes and the included screws to secure in place. mounting screw holes on the door.
- Page 6 Fig. 1 Fig. 2...
-
Page 7: Optional Accessories
On small or light doors, one hinge can be deactivated to allow the same smooth closing motion. Fig. 3. Check Rockler.com for updates. If you have further questions, please contact our Technical Support Department at 1-800-260-9663 or support@rockler.com... - Page 8 43870 Distributed by Rockler Companies, Inc. Rev 08/18 Medina, MN 55340...
