Current LOOP 4300 Quick Start Manual page 7

Step 4. Install eFlux Wave Pumps
1. Unpack all components from eFlux Accessory Wave Pump boxes.
2. Choose a mounting location inside the aquarium on one of the vertical glass walls for your
wave pumps. Clean location of any dirt, algae or calcium deposits.
3. Install cable wrapping around wave pump
cable. This protects the pump cable from
triggerfish, urchins and other animals that
may damage the pump cable. Place pump
prefilter over pump end.
4. Carefully separate magnet from pump and
place pump into position in the aquarium.
Attach pump to tank using magnet. Swivel
and adjust pump as desires.
5. Route wave pump cables behind stand to
Power Center. Plug wave pumps into wave
pump ports P1 and P2 on eFlux Wave Pump
Manifold HUB (middle blue HUB). Ensure a drip
loop is in place.
6. Wrap any excess cable together and use
Power Center Tie Wrap to attach the excess
cable.
7. Press light blue wave pump POWER key
on remote, turn wave pumps on.
8. Follow programming steps included with
Orbit Marine IC PRO LED light to program
pumps and adjust flow mode and flow
rate on wave pumps.
NOTE: READ ALL SAFETY INSTRUCTIONS
INCLUDED WITH EACH PRODUCT
Page 7
eFlux Wave Pump Installation
LOOP® Marine Bundle Kit
Install wave pump
4
attach with magnet
5
Connect to P2
eFlux Wave Pump
3 Install cable
wrapping & optional
pump prefilter
5
Connect to P1
P3 P1
P2
Manifold HUB
