ATI Technologies Q45R O & M Manual

Portable orp measurement system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Measurement System
Home Office
Analytical Technology, Inc.
6 Iron Bridge Drive
Collegeville, PA 19426
Phone: 800-959-0299
610-917-0991
Fax:
610-917-0992
Email: sales@analyticaltechnology.com
O & M Manual
Model Q45R
Portable ORP
European Office
ATI (UK) Limited
Unit 1 & 2 Gatehead Business Park
Delph New Road, Delph
Saddleworth OL3 5DE
Phone: +44 (0)1457-873-318
Fax:
+ 44 (0)1457-874-468
Email: sales@atiuk.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q45R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATI Technologies Q45R

Summary of Contents for ATI Technologies Q45R

  • Page 1 O & M Manual Model Q45R Portable ORP Measurement System Home Office European Office Analytical Technology, Inc. ATI (UK) Limited 6 Iron Bridge Drive Unit 1 & 2 Gatehead Business Park Collegeville, PA 19426 Delph New Road, Delph Phone: 800-959-0299...

  • Page 2: Table Of Contents

    PART 1 - INTRODUCTION ........4 General............4 System Checks ......... 34 Features ............4 Instrument Checks ........34 Q45R System Specifications ..... 5 Display Messages ........35 Q45R Performance Specifications ..... 6 PART 7 – MAINTENANCE AND PART 2 – INSTRUMENT TROUBLESHOOTING ........
  • Page 3 Table of Figures 1 - P ..................7 IGURE ORTABLE ANDLE IEWS 2 - B ..................... 8 IGURE ULKHEAD ONNECTION 3 - S ....................9 IGURE ENSOR ONNECTION 4 - S ..........10 IGURE ENSOR ONNECTIONS OMBINATION LECTRODES 5 - E ..............11 IGURE XTERNAL...

  • Page 4: Part 1 - Introduction

    Q25 series sensors or with combination-style electrodes. Features • Standard Q45R electronic transmitters are designed to be a fully isolated, battery powered instrument. The monitor can be quickly converted to either a loop power transmitter or line powered analyzer.

  • Page 5: Q45R System Specifications

    Part 1 – Introduction Q45R ORP System Q45R System Specifications Enclosure NEMA 4X, polycarbonate, stainless steel hardware, weatherproof and corrosion resistant, HWD: 4.4" (112 mm) × 4.4" (112 mm) × 3.5" (89 mm) Mounting Options Handheld w/ Nylon Carrying Strap Weight 1 lb.

  • Page 6: Q45R Performance Specifications

    Part 1 – Introduction Q45R ORP System Outputs: Two 0-2.5 VDC isolated outputs are provided on for connection to data recorders, etc. Battery Life: Approximately 6-12 months with alkaline battery under non-continuous use. Approximately 10 days continuous use (without backlight)

  • Page 7: Handle/Mounting

    Part 2 – Instrument Handle/Mounting General The Q45R Portable ORP System comes complete with a specially designed handle that allows the system to be comfortably carried, or quickly strapped to a railing. Although the system is designed to be a portable system, it can be permanently mounted for longer term field use.

  • Page 8: Part 3 - Sensor Electrical Installation

    Part 3 – Sensor Electrical Installation General The sensor cable can be quickly connected to the Q45 terminal strip by matching the wire colors on the cable conductors. Keep signal cable away from AC power lines, adjustable frequency drives, motors, or other noisy electrical signal lines. Direct Sensor Connection The sensor cable should be routed into the enclosure through the right hand cord grip on the bottom of the enclosure.

  • Page 9: Figure 3 - Sensor Connection

    Part 3 – Installation Q45R ORP System Figure 3 - Sensor Connection O&M Manual Rev-C (7/15)

  • Page 10: Combination Electrode Connection

    Q45R ORP System Combination Electrode Connection The Q45R may also be used with non-amplified simple combination electrodes (see Figure 4). Note that a wire jumper must be installed from Terminal 3 to Terminal 8. The user must also select Sensor Type 2 within the Config Menu (see Section 4.11).

  • Page 11: External Temperature Compensation

    Part 3 – Installation Q45R ORP System External Temperature Compensation All Q25 sensors include an integral Pt1000 RTD. The Q45 series instruments also allow user-supplied external Pt1000 or Pt100 elements to be connected to the temperature input, as shown in Figure 5. Note that when using the Pt100...

  • Page 12: Part 4 - Configuration

    Part 4 – Configuration General To turn the system ON, simply press and hold the MENU key for approximately 5 seconds and the display will come on. To turn the unit off, press and hold the ENTER key until the display shuts off (about 3 seconds). Note that the unit must be in the MEASURE menu in order for the 3-second key press to operate.

  • Page 13: Figure 6 - Battery Board Connection

    Part 4 – Configuration Q45R ORP System POWER CABLE DC BATTERY BOARD (REAR OF ENCLOSURE) Figure 6 - Battery Board Connection The first (S1) is an On/Off slide switch. This switch must be in the ON position for operation. Turn it to OFF if you do not intend to operate the monitor in the next week or two.

  • Page 14: Battery Power Circuit Board

    Part 4 – Configuration Q45R ORP System MODE This switch is used to set the voltage at which monitor will shut off when powered by internal batteries. Alkaline batteries can normally be run down to about 0.8 volts. When using alkaline batteries, the mode switch is in the OFF position (factory default).

  • Page 15: User Interface

    Part 4 – Configuration Q45R ORP System User Interface The user interface for the Q45 Series instrument consists of a custom display and a membrane keypad. All functions are accessed from this user interface (no internal jumpers, pots, etc.). RELAY...

  • Page 16: Keys

    Part 4 – Configuration Q45R ORP System Keys All user configuration occurs through the use of four membrane keys. These keys are used as follows: MENU/ESC To scroll through the menu section headers or to escape from anywhere in software. The escape sequence allows the user to back out of any changes in a logical manner.
  • Page 17 Part 4 – Configuration Q45R ORP System Lower Line During normal operation, the lower line of the display indicates user-selected secondary measurements that the system is making. This also includes calibration data from the last calibration sequence and the transmitter model number and software version.

  • Page 18: Software

    Icon B battery power is low. Software The software of the Q45R is organized in an easy to follow menu-based system. All user settings are organized under five menu sections: Measure, Calibration [CAL], Configuration [CONFIG], Control [CONTROL] and Diagnostics [DIAG].
  • Page 19 Part 4 – Configuration Q45R ORP System The starting (default) screen is always the Measure Menu. The UP arrow key is used to select the desired display. From anywhere in this section the user can press the MENU key to select one of the four Menu Sections.

  • Page 20: Figure 8 - Software Map

    Part 4 – Configuration Q45R ORP System MENU MEASURE CONFIG CONTROL DIAG SECTIONS Temperature Set 0V #1 Entry Lock Cal ORP Set Hold Vout #1 Set 2.5V #1 LIST Set Delay Cal Temp Fault List Vout #2 ITEMS Set 0V #2...

  • Page 21: Measure Menu [Measure]

    Part 4 – Configuration Q45R ORP System Measure Menu [MEASURE] The default menu for the system is the display-only menu MEASURE. This menu is a display-only measurement menu, and has no changeable list items. When left idle, the instrument will automatically return to this menu after approximately 30 minutes.

  • Page 22: Calibration Menu [Cal]

    Press ENTER to initiate user entry mode and the first digit will flash. Use arrow keys to modify value. See end of manual for the Q45R lock/unlock code. Press ENTER to toggle lock setting once code is correct.
  • Page 23 Part 4 – Configuration Q45R ORP System minimize the calibration timing. Press ENTER to initiate user entry mode, and the value will flash. Use the arrow keys to modify value; range is 0.1 to 9.9 minutes. Press ENTER to store the new value.

  • Page 24: Control Menu [Control]

    Part 4 – Configuration Q45R ORP System Out#2 Mode This function sets analog output #2 for either temperature (default) or mV ORP. Press ENTER to initiate user entry mode, and the entire value will flash. Use the UP arrow key to modify the desired value;...
  • Page 25 Part 4 – Configuration Q45R ORP System Set Hold The Set Hold function locks the voltage output values on the present process value. This function can be used prior to calibration, or when removing the sensor from the process, to hold the output in a known state. Once HOLD is released, the outputs return to their normal state of following the process input.
  • Page 26 Part 4 – Configuration Q45R ORP System Sim Out The Sim Out function allows the user to simulate the mV level of the instrument to check the output settings. The user enters a mV value directly onto the screen, and the output responds as if it were actually receiving the signal from the sensor.
  • Page 27 Part 4 – Configuration Q45R ORP System BackLight The Back-light screen is used to set the operating conditions under which the backlight will turn on. The default is OFF, (Always Off). Other selections are AUTO, where the light comes on whenever any key is pressed. The light will...

  • Page 28: Part 5 - Calibration

    Part 5 – Calibration Overview and Methods The instrument must be calibrated periodically to maintain a high degree of measurement accuracy. Frequency of calibration must be determined by the application. High temperature applications or applications involving other extreme operating conditions may require more frequent calibration than those that operate at more ambient level temperatures.

  • Page 29: Sensor Offset

    Part 5 –Calibration Q45R ORP System period of time as the glass reference electrode ages. Slope calibrations can remove this error along with very small inherent gain errors in the sensor preamp and electrodes. The transmitter will not allow calibrations on a sensor with a slope less than 60% or more than 140%.

  • Page 30: 1-Point Calibration Explained

    Part 5 –Calibration Q45R ORP System 5.14 1-Point Calibration Explained The 1-point calibration method is generally known as the "grab sample" calibration method. In the 1-point calibration method, the sensor may be removed from the application and placed into the mV solution. It may also be left in the measurement process and calibrated by reference.

  • Page 31: Performing A 1-Point Calibration

    Part 5 –Calibration Q45R ORP System 7. Wait for approximately 10-15 seconds. 8. The screen will display the measured mV value. If the user chooses to change this value, the arrow keys can be used to modify the value. Any value between -1000 and +2000 mV can be entered.
  • Page 32 Part 5 –Calibration Q45R ORP System 1. Determine whether the calibration will be done on-line or with the sensor removed and placed into a mV solution. If the sensor is removed from the application, rinse and clean if necessary. 2. If the sensor has been removed and placed into a mV solution, allow sensor to temperature equilibrate with the solution as much as possible.

  • Page 33: Temperature Calibration

    Part 5 –Calibration Q45R ORP System Temperature Calibration The temperature input is factory calibrated for the highest accuracy. Temperature calibration is not recommended; however, it is provided for applications in which very long cable lengths are needed. For example, at 50 feet, readings may be off ±0.2 °C.

  • Page 34: Part 6 - System Maintenance

    Part 6 – System Maintenance System Checks 1. If the FAIL icon is flashing on the display, check the Fault List to determine the cause of the failure. To access the Fault List, press the MENU/ESC key until the DIAG menu appears. Then press the UP arrow key until the Fault List appears. Press the ENTER key to access the Fault List, and the highest priority fault message will be displayed.

  • Page 35: Display Messages

    Part 6 –System Maintenance Q45R ORP System Display Messages The Q45 Series instruments provide a number of diagnostic messages that indicate problems during normal operation and calibration. These messages appear as prompts on the secondary line of the display or as items on the Fault List (see Section 4.13).
  • Page 36 Part 6 –System Maintenance Q45R ORP System The following messages will appear as items on the Fault List: MESSAGE DESCRIPTION POSSIBLE CORRECTION Sensor High The raw signal from the sensor is too Check wiring connections to sensor. high. Sensor Low The raw signal from the sensor is too Check wiring connections to sensor.
  • Page 37 Part 6 –System Maintenance Q45R ORP System MESSAGE DESCRIPTION POSSIBLE CORRECTION ORP Cal Fail Failure of ORP calibration. Clean sensor, get fresh cal solutions, regenerate sensor (if necessary) and redo calibration. If still failure, sensor slope may be less than 80% or offset may be out of range.

  • Page 38: Part 7 - Maintenance And

    Part 7 – Maintenance and Troubleshooting Cleaning the Sensor Keep the sensor as clean as possible for optimum measurement accuracy - this includes both the saltbridge and the measuring electrode glass. Frequency of cleaning depends upon the process solution. Carefully wipe the measuring end of the sensor with a clean soft cloth. Then rinse with clean, warm water - use distilled or de-ionized water if possible.

  • Page 39: Replacing The Saltbridge And Reference

    Part 7 –Troubleshooting Q45R ORP System Replacing the Saltbridge and Reference Buffer Solution 1. Hold the sensor with the process electrode pointing up. Place a cloth or towel around the saltbridge. Turn the saltbridge counterclockwise (by hand) to loosen and remove the saltbridge. Do NOT use pliers.

  • Page 40: 7.3 Troubleshooting

    Part 7 –Troubleshooting Q45R ORP System 7.3 Troubleshooting The first step in resolving any measurement problem is to determine whether the trouble lies in the sensor or the transmitter. Since measurement problems can often be traced to dirty sensor electrode glass and/or saltbridge, cleaning the sensor using the method outlined in Section 7.3 should always be the first step...
  • Page 41 Part 7 –Troubleshooting Q45R ORP System 5. Reconnect the yellow and white wires. 6. Connect the multimeter’s positive (+) lead to the red wire and its negative (-) lead to the green wire. With the sensor in the first mV solution at approximately 20-30 ºC, measure the DC millivolts.

  • Page 42: Spare Parts

    Spare Parts Part No. Description 07-0008 Q45R ORP transmitter, 3VDC, Dual 0-2.5 VDC outputs ORP Sensor with 30’ cable, Pt 07-0065 ORP Sensor with 30’ cable, Au 07-0066 05-0060 Saltbridge 05-0057 Regeneration Kit (saltbridge & fill solution) 09-0042 200 mV ORP Solution, 500 mL...
  • Page 43 PRODUCT WARRANTY Analytical Technology, Inc. (Manufacturer) warrants to the Customer that if any part(s) of the Manufacturer's equipment proves to be defective in materials or workmanship within the earlier of 18 months of the date of shipment or 12 months of the date of start- up, such defective parts will be repaired or replaced free of charge.
