Use & Care Guide
Guide d'utilisation et d'entretien
Manual de uso y cuidado
English / Français / Español
Models/Modèles/Modelos: 665.1309*
Kenmore
ULTRA WASH Dishwasher
Lave-vaisselle ULTRA WASH
Lavavajillas ULTRA WASH
* = color number, numéro de couleur, número de color
P/N W11411289A
Transform SR Brands Management LLC,
Hoffman Estates, IL 60179 U.S.A.
www.kenmore.com
®
®
®
®

Advertisement

Table of Contents
loading

Related Manuals for Kenmore ULTRA WASH 665.1309 Series

Summary of Contents for Kenmore ULTRA WASH 665.1309 Series

  • Page 1 Use & Care Guide Guide d’utilisation et d’entretien Manual de uso y cuidado English / Français / Español Models/Modèles/Modelos: 665.1309* Kenmore ® ® ULTRA WASH Dishwasher ® Lave-vaisselle ULTRA WASH ® Lavavajillas ULTRA WASH * = color number, numéro de couleur, número de color...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PROTECTION AGREEMENTS ........2 Top Rack Loading ............. 13 DISHWASHER SAFETY ..........4 Bottom Rack Loading ............14 WHAT’S NEW IN YOUR DISHWASHER ....... 6 DISHWASHER USE ............ 16 Energy ..................6 Cycles and Options Information ........16 Performance ................6 Dishwasher Control Section ..........
  • Page 3 Sears authorized service representative. For warranty coverage details to obtain free repair or replacement, visit the web page: www.kenmore.com/warranty All warranty coverage applies for only 90 DAYS from the sale date if this appliance is ever used for other than private household purposes.

  • Page 4: Dishwasher Safety

    DISHWASHER SAFETY IMPORTANT SAFETY INSTRUCTIONS WARNING: When using the dishwasher, follow basic precautions, including the following: Read all instructions before using the dishwasher. Do not tamper with controls. Use the dishwasher only for its intended function. Do not abuse, sit on, or stand on the door, lid, or dish racks of the dishwasher.
  • Page 5 WARNING For a grounded, cord-connected dishwasher: The dishwasher must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. The dishwasher is equipped with a cord Tip Over Hazard having an equipment-grounding conductor and a grounding plug.

  • Page 6: What's New In Your Dishwasher

    WHAT’S NEW IN YOUR DISHWASHER Energy Congratulations on purchasing your water and energy efficient dishwasher! This dishwasher cleans by spraying the dishes with water and pauses to allow the detergent to soak into and release the soils on the dishes. The cycles are longer due to the soak and the pauses for exceptional cleaning. Models with SmartWash ®...

  • Page 7: Parts And Features

    Pressurized spray nozzle and variable speed motor provide effective cleaning. Model and serial number label Water inlet opening Kenmore PowerWave spray arm delivers 80% more water coverage than a traditional spray arm and sweeps dirty dishes clean from not just one, but two sides.

  • Page 8: Start-Up / Quick Reference (Varies By Model)

    START-UP / QUICK REFERENCE (VARIES BY MODEL) ULTRA WASH removable filters provide peak 1 Hour Wash - When you need fast results. ® performance. High Efficiency dishwashers run longer to Cleaning the filters periodically save water and energy just as driving a car helps keep the dishwasher slower saves on gas.

  • Page 9: Ultra Wash ® Filtration System

    ULTRA WASH FILTRATION SYSTEM ® Your dishwasher has the latest technology in dishwasher filtration. This triple filtration system minimizes sound and optimizes water and energy consumption while providing superior cleaning performance. Throughout the life of your dishwasher, the filter will require maintenance to sustain peak cleaning performance.

  • Page 10: Dishwasher Efficiency Tips

    Filter Removal Turn the Upper Filter Assembly 1/4 turn counterclockwise and lift out. Grasp the Lower Filter in the circular opening, lift slightly, and pull forward to remove. Locating tab Clean the filters as shown below. To remove Upper Filter Assembly Filter Cleaning IMPORTANT: Do not use wire brush, scouring pad, etc., as they may damage the filters.

  • Page 11: Detergent And Rinse Aid

    DETERGENT AND RINSE AID Detergent Rinse Aid USE RINSE AID FOR Full BETTER DRYING Lock Refill IMPORTANT: Use only automatic dishwashing detergent. Hand IMPORTANT: Your dishwasher is designed to use a liquid rinse dishwashing detergent will produce excessive suds and overflow aid.

  • Page 12: Loading

    LOADING Loading for Best Cleaning and Drying Performance 1. Angle dirtiest dish surfaces downward and allow space Angle concave surfaces such as the bottom of coffee for water to flow up through each rack and between cups to allow water to drain and improve drying dishware.

  • Page 13: Top Rack Loading

    Top Rack Loading Loading Recommendations Place cups and glasses in the rows between tines. Placing them over the tines can lead to breakage and water spots. To avoid damage to your delicate items, be sure china, crystal, stemware and other similar items do not touch during dishwasher operation. Load lightweight and dishwasher-safe plastic items only in the top rack.

  • Page 14: Bottom Rack Loading

    Bottom Rack Loading Loading Recommendations The bottom rack is best suited for plates, pans, casseroles, and utensils. (See recommended loading patterns shown.) Load small items in the bottom rack only if they are secured in place. Load plates, soup bowls, etc., between tines. Load bowls securely between the rows of tines.
  • Page 15 Loading Tall Items You can wash larger items such as pots, roasters, and cookie sheets in the bottom rack by removing the top rack. See “Top Rack Loading” section. IMPORTANT: Do not block detergent dispenser. Loading Silverware Use suggested loading patterns, as shown, to better clean your silverware. Use the slots in the covers to keep your silverware separated for optimum wash.

  • Page 16: Dishwasher Use

    DISHWASHER USE Cycles and Options Information Estimated Range of WashTime* Water Usage Cycles Displayed: Gallons H:MM (Liters) SmartWash ® cycle 3.4 to 7.4 2:30 The most advanced and versatile cycle. This cycle senses the load size, soil amount, and toughness (12.8 to 28.0) of soil.

  • Page 17: Dishwasher Control Section

    Added Can be selected Added time Water* Options What it does with to cycle Gallons (Liters) High Temp Raises the main SmartWash ® 0 - 3.9 wash temperature to Pots & Pans 0:05 to 0:13 Raises main wash temperature to improve cleaning for (0 - 14.6) 135°F (57°C).

  • Page 18: Dishwasher Feedback Section

    Dishwasher Feedback Section Status Indicator Lights The full lit display will glow for wash, drying, sanitized, and complete. It will also display the estimated remaining time for the cycle in hours and minutes. The indicator light (on some models) is green when running and off when the cycle is complete. Selecting Cycles and Options 1.

  • Page 19: Washing Special Items

    WASHING SPECIAL ITEMS If you have doubts about washing a particular item, check with the manufacturer to see if it is dishwasher safe. Material Dishwasher Safe? Comments Aluminum High water temperature and detergents can affect finish of anodized aluminum. Disposable Aluminum Do not wash disposable aluminum pans in the dishwasher.

  • Page 20: Dishwasher Care

    DISHWASHER CARE Cleaning Cleaning the exterior In most cases, regular use of a soft, damp cloth or sponge and a mild detergent is all that is necessary to keep the outside of your dishwasher looking nice and clean. If your dishwasher has a stainless steel exterior, a stainless steel cleaner is recommended.

  • Page 21: Troubleshooting

    TROUBLESHOOTING CHECK THESE POINTS TO HELP SAVE YOU TIME AND MONEY. PROBLEM SOLUTION DISHWASHER DOES NOT NOTE: It is normal for the dishwasher to repeatedly pause several times during a cycle. If the Start/Resume light is blinking, close the door and press START/RESUME or press START/ RESUME and close the door within 3 seconds.
  • Page 22 PROBLEM SOLUTION WATER REMAINS IN THE Be sure the cycle has completed. The Complete indicator will be turned on in the display and the TUB/WILL NOT DRAIN front status light (on some models) will be off. If it has not completed, you will need to resume the cycle by closing the door and pressing START/RESUME or press START/RESUME and close the door within 3 seconds.
  • Page 23 PROBLEM SOLUTION CLOUDY OR SPOTTED NOTES: DISHWARE (AND HARD Liquid rinse aid, in addition to all in one tablets or packs, is necessary for drying and to reduce WATER SOLUTION) spotting. Use the correct amount of detergent. Confirm that the cloudiness is removable by soaking the item in white vinegar for 5 minutes. If the cloudiness disappears, it is due to hard water.
  • Page 24 Para pedir servicio de reparación a domicilio, y ordenar piezas Para pedir servicio de reparación a domicilio y ordenar piezas 1-844-553-6667 www. kenmore. com ® W11411289A ©2020 Transform SR Brands LLC 01/20 ® Registered Trademark /...
