STAINLESS STEEL ROTARY DRUM PUMP

L-SSRP

SS Handle

SS Hardware

SS 2" Bung adaptor

INTRODUCTION

Thank you for purchasing a Lubemate Stainless Steel Rotary Drum Pump. Your stainless steel rotary drum pump with

PTFE vanes has been designed and manufactured to reliably dispense a wide range of fluids such as water based

media, anti-freeze, acids, chemicals, all petroleum based products, lacquers, thinners and Urea/DEF.

The pump is suitable for use on 60-205L metal or plastic drums.

SPECIFICATIONS

Pump type:

Rotary vane

Wetted materials:

304 SS, PTFE and Viton®

Pump inlet/outlet:

3/4" BSPT (F)

Flow rate:

Up to 4L=20 turns

lubematebymacnaught.com

INSTRUCTION MANUAL

| Instruction manual

SS Outlet tube

3/4"(F) Outlet thread

SS Pump body

3/4"(F) Inlet thread

3 Piece SS

suction tube

Note: Please check fluid compatibility before

using this pump on acids or chemicals.

L-SSRP-im-issue1-2017

Need help?

Do you have a question about the Lubemate L-SSRP and is the answer not in the manual?

Page 1 ® INSTRUCTION MANUAL STAINLESS STEEL ROTARY DRUM PUMP L-SSRP SS Outlet tube 3/4"(F) Outlet thread SS Handle SS Pump body SS Hardware 3/4"(F) Inlet thread SS 2" Bung adaptor 3 Piece SS suction tube INTRODUCTION Thank you for purchasing a Lubemate Stainless Steel Rotary Drum Pump. Your stainless steel rotary drum pump with PTFE vanes has been designed and manufactured to reliably dispense a wide range of fluids such as water based media, anti-freeze, acids, chemicals, all petroleum based products, lacquers, thinners and Urea/DEF.
Page 2 ® STAINLESS STEEL ROTARY DRUM PUMP GENERAL INFORMATION INSTALLATION and USE This self priming pump can pump fluid in reverse 1. Assemble the outlet tube to if required . the pump head. Note: Use PTFE tape or other Please take a few moments to read this manual suitable thread sealant.
Page 3 ® STAINLESS STEEL ROTARY DRUM PUMP PRIMING Start rotating the handle until fluid starts flowing from the outlet spout. Outlet oultet In the unusual event where the pump fails to prime. Remove the outlet tube and pour about 30mL of the same type of liquid into the pump outlet, then re-fit the outlet spout and turn the handle to re-prime the pump.
Page 4 ® Lubemate is a practical, cost-effective range of ® equipment brought to you by the trusted team at Macnaught. All Lubemate products are specially selected by our experienced technical team at Macnaught , ensuring they meet our ® strict quality standards.
