Appendix | Control Menu
Settings USB Scaling Standard scaling
Two-point scaling
Digital Error output 1 / Er-
output ror output 2
Analog output Output area
1, Analog
output 2
Output signal
Scaling
C-Box/2A
For standard calibration, the entire measuring range of the sensor / controller is
output.
Start of range (mm) Value
End of range (mm)
Sensor 1: Error output 1 / Sensor 1: Error output 2 /
Sensor 2: Error output 1 / Sensor 2: Error output 2 /
Sensor 1: Measurement value / Sensor 1: Intensity /
Sensor 1: Shutter time / Sensor 1: Reflectivity /
Sensor 2: Measurement value / Sensor 2: Intensity /
Sensor 2: Shutter time / Sensor 2: Reflectivity /
C-Box/2A: Measurement value / Level low / Level high
Inactive / 0V ... 5V / -5V ... 5V / -10V ... 10V /
4mA ... 20mA
Fixed output value / Sensor 1: Measurement
value / Sensor 1: Intensity/ Sensor 1: Shut-
ter speed / Sensor 1: Reflectivity / Sensor 2:
Measurement value / Sensor 2: Intensity/ Sen-
sor 2: Shutter speed / Sensor 2: Reflectivity /
C-Box/2A: Measurement value
Standard scaling
Two-point scaling Start of range
(mm)
End of range
(mm)
The two-point scaling requires the specification of the
beginning and end of the
Value
Specification of analog output, current or
voltage with selectable value range.
The data which are provided for the trans-
mission are to activate in the dropdown
men, see 6.6.6.
At Standard scaling outputs the entire mea-
suring range of the sensor / controller.
Value The two-point scaling requires the specifica-
tion of the beginning and end of the range.
Value
range., see 6.6.4.
The data which are provided for
the transmission are to activate in
the dropdown menu, see 6.6.5.
