3. Description
The system controls offer an easy to use guide for the switch programming. Using an LCD
display the fill measurement is shown in 1 % stages (in relation to the height of the
tank).The sensor operates with a 12 volt supply. All programmed values such as the tank
height are retained after disconnection of the power supply or after a power-cut.
Performance features:
– Fill level measurement readout in 1% steps and with an additional bar type indicator
– In 1% steps freely variable choice of the switching points for the drinking water refill
– Automatic flushing of the system (choice of intervals in day and time are possible)
– Dialogue oriented user guidance (choice of language)
– Equipment indication using 3 additional LED
– Supervision of the measurement pick-up and the sensor
– Error indication in simple text
Technical data:
Control electronics
Operating voltage
Fused
Power consumption : 3VA
Tank height
Measurements [mm] : 155x165x90
Pump connection
Operating voltage
Pump capacity
Only the control electronics in the device are protected by the fuse. Valves and
pump connections are not protected. These are protected only by the mains sup-
ply via the mains fuse.
: 230V AC
: 50mA slow-blow
: 3m
(optional 6m)
: 230V AC
: max. 1200VA
Measurement sensors
Measurement voltage
Measurement frequency
Data cable length
Measurements [mm]
Valve connection
Operating voltage
Output current
9
: 12V DC
: (0,2-20)kHz
: 20m
(max. 50m)
: 90x80x50
: 230V AC
: max. 1A
