Midco LNB 500 Series Installation And Service Instructions Manual

Installation and Service Instructions
LNB 1000
!
WARNING: If the information in these instructions
is not followed exactly, a fi re or explosion may result,
causing property damage, personal injury or death.
• In the United States, installation must conform with local codes
or in the absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1-latest edition available from American
National Standard Institute. Further reference should be made
to the recommendation of your fuel supplier.
!
• WARNING: Additions, changes, conversions and service
must be performed by an authorized Midco representative,
service agency or the fuel supplier. Use only MIDCO
specifi ed and approved parts.
• INSTALLER: Inform and demonstrate to the user the correct
operation and maintenance of the gas utilization equipment.
Inform the user of the hazards of storing fl ammable liquids
and vapors in the vicinity of this gas utilization equipment
and remove such hazards. Affi x this manual and associated
literature to the burner or equipment.
• CODE COMPLIANCE IS THE SOLE RESPONSIBILITY OF
THE INSTALLER.
• USER: Retain this manual for future reference. If other than
routine service or maintenance as described in this manual
and associated literature is required, contact a qualifi ed service
agency. DO NOT ATTEMPT REPAIRS. An inadvertent service
error could result in a dangerous condition.
AVOID ERROR IN PARTS SELECTION. When ordering use
complete MIDCO Part Number and Description. Furnish Burner Model
Number, Bill of Material Number and Date Code (if available) from the
specifi cation plate found on the product
IMPORTANT: Availability of parts as well as specifi cations are subject
to change without notice. Please consult factory for item availability.
Midco® International Inc.
4140 West Victoria Street
Chicago, Illinois 60646
tel 866.705.0514
fax 866.580.8700
web www.midcointernational.com
e-mail sales@midcointernational.com
MADE in the USA
SAFETY INFORMATION TERMS: The following terms are used to identify hazards, safety precaution of special
notations and have standard meanings throughout this manual. They are printed in all capital letters using a bold
type face as shown below, and preceded by the exclamation mark symbol. When you see the safety alert symbol and
one of the safety information terms as shown below, be aware of the hazard potential.
DANGER:
WARNING:
!
CAUTION:
Quality Designed for Proven Performance
LNB 500 &
LNB 1000 Series
Low NO x Burners
Do not store or use gasoline or other fl ammable vapors and liquids in
the vicinity of this or any other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately phone your gas supplier from another
building. Follow the gas supplier's instructions. If
you cannot reach your gas supplier call the fi re
department.
Installation and service must be performed by a qualifi ed installer,
service agency or the gas supplier.
BURNER MODEL:
BILL OF MATERIAL
NUMBER:
SERIAL NUMBER #: ______________________________________
WIRING DIAGRAM: ______________________________________
Name: _______________________________________________
Address: _______________________________________________
_______________________________________________
Phone: _______________________________________________
Date of Installation: ______________________________________
Identifi es the most serious hazards which will result in severe personal injury or death.
Signifi es a hazard that could result in personal injury or death.
Identifi es unsafe practices which would result in minor personal injury or product and
property damage.
With Chamber
WHAT TO DO IF YOU SMELL GAS:
______________________________________
______________________________________
FOR SERVICE CONTACT
319
8471 91
Printed in USA
