Features
• 25mm of Peak to Peak Excursion
• Dual or Single 4 Ohm Voice Coil Models
• 12" or 10" versions with hidden screw surround
• High Excursion CAE/CAD Motor Design
KlaraForm Vented Kapton Former technology reduces
distortion by reducing heat and resistance
• UNICAP Technology provides a stiff piston for
pronounced SPL
Subwoofer Manual
Models: RX2 12D, RX2 12S
• Phoeniroll Surround Technology promotes
linear motion
• Torriform Voice Coil Technology:
Effectively dissipates heat and minimizes distortion
• Nickel Plated 12 Gauge Speaker Terminal
• Optimized for Sealed or Vented Enclosures
• Powder Coated Anti-Resonant Steel Basket
© 2018 Phoenix Gold • www.phoenixgold.com
RX2 10D, RX2 10S
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Phoenix Gold RX2 12D
Summary of Contents for Phoenix Gold RX2 12D
- Page 1 Subwoofer Manual Models: RX2 12D, RX2 12S RX2 10D, RX2 10S Features • 25mm of Peak to Peak Excursion • Phoeniroll Surround Technology promotes • Dual or Single 4 Ohm Voice Coil Models linear motion • 12” or 10” versions with hidden screw surround •...
-
Page 2: Enclosure Recommendations
Enclosures ENCLOSURE INFORMATION Phoenix Gold subwoofers are over engineered and overbuilt in virtually every way conceivable. It is important that the subwoofer’s enclosure is built to these same exacting standards. The enclosure must be constructed of at least .75 inch MDF. Screws or air staples are excellent construction fasteners when used with a strong bonding “yellow”... -
Page 3: System Diagrams
(Optimal Setup) RX2 250.1 RX2 500.1 RX + (2) RX2 12S or (2) RX2 10S RX2 250.1 or RX2 500.1 + (1) RX2 12D or (1) RX2 10D All voice coils are wired in parallel for 2 Ohm load. All voice coils are wired in parallel for 2 Ohm load. -
Page 4: Specifications
LIMITED WARRANTY ON SUBWOOFERS Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) years from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. - Page 5 Subwoofer Owner’s Manual A Power Brand of AAMP Global. Clearwater, Florida P: 866-788-4237 info@phoenixgold.com www.phoenixgold.com © Copyright 2018 © 2018 Phoenix Gold • www.phoenixgold.com Designed and Engineered in the USA...
