Phoenix Gold RSD10D Specifications

10" & 12" competition subwoofer

Advertisement

Quick Links

COMPETITION SUBS
FEATURES
High Excursion Butyl Rubber Surround
Expanded Polypropylene Cone
Non-Linear Spider
Rugged Dual Voice Coils
Optimized Magnet/Motor Structure
Rigid Cast Aluminum Frame
Heavy Duty Rubber Gasket
Performance Design
SUBWOOFERS
FEATURES
Available in Dual or Single Coil
CAE/CAD Performance Design
Injection Molded Aluminum Plated
Polypropylene Cone
Butyl Rubber Surround
Flat Linear Roll Spider
Optimized Magnet/Motor Structure
Reversible Rubber Mounting Gasket
Rigid Powder Coated Anti-Resonant
Steel Frame
Grill Sold Separately - RSd G10/G12
NEW
10" COMPETITION SUBWOOFER
RSdC102 / RSdC104
SPECIFICATIONS
Power Handling (RMS/Peak): 600W/1200W
Impedance (RSdC102): 2/2 Ω
Impedance (RSdC104): 4/4 Ω
Frequency Response: 29Hz - 300Hz
Sensitivity (RSdC102): 93dB @ 2.83V/1M
Sensitivity (RSdC104): 89dB @ 2.83V/1M
Mounting Diameter: 8
"
15
16
Mounting Depth : 5
"
3
4
10" SUBWOOFER
RSd10 / RSd10d
SPECIFICATIONS
Power Handling (RMS/Peak): 350W/700W
Impedance (RSd10): 4 Ω
Impedance (RSd10d): 4/4 Ω
Frequency Response: 25Hz - 200Hz
Sensitivity (RSd10): 88dB @ 2.83V/1M
Sensitivity (RSd10d): 91dB @ 2.83V/1M
Mounting Diameter: 9
"
1
8
Mounting Depth : 5
"
3
8
2 Voice coils measured in parallel
NEW
12" COMPETITION SUBWOOFER
RSdC122 / RSdC124
SPECIFICATIONS
Power Handling (RMS/Peak): 600W/1200W
Impedance (RSdC122): 2/2 Ω
Impedance (RSdC124): 4/4 Ω
Frequency Response: 27Hz - 250Hz
2
Sensitivity (RSdC122): 94dB @ 2.83V/1M
2
Sensitivity (RSdC124): 92dB @ 2.83V/1M
Mounting Diameter: 10
Mounting Depth : 6
12" SUBWOOFER
SPECIFICATIONS
Power Handling (RMS/Peak): 350W/700W
Impedance (RSd12): 4 Ω
Impedance (RSd12d): 4/4 Ω
Frequency Response: 25Hz - 200Hz
Sensitivity (RSd12): 88dB @ 2.83V/1M
Sensitivity (RSd12d): 91dB @ 2.83V/1M
2
Mounting Diameter: 10
Mounting Depth : 6
2
2
"
3
4
"
1
4
RSd12 / RSd12d
2
"
15
16
"
1
4
