  • Page 1 AAE320...
  • Page 2 The New Besam Swing door operator PowerSwing...
  • Page 3 Main models of the PowerSwing operator Standard cover Special cover Double door operators Door leaf-mounted...
  • Page 4 •  The operator works electro-hydraulically. •  Closing power from a coil spring •  The open position is kept by a hydraulic valve. •  ”Lock kick” to overcome the resistance of a striking plate •  Dimension standard cover LxHxD 716x110x110 mm...
  • Page 5 Identification PowerSwing 10. Extension unit, EXA (option) 11. End plate Mounting plate 12. Programme selector, PS-3 (option) Motor/ Pump Spring tube 13. Cover Cable inlet Valve 14. Bearing sleeve 8.  Mains connection 4.  Hydraulic unit 15. Cable holder Control unit, CSDA Drive shaft 16.
  • Page 6 Arm systems PULL Arm system PUSH Arm system...
  • Page 7 Wall mounted operator, arm system PUSH •  Decide X •  Draw a line on the wall for the underside of the mounting plate Note! •  Door adaptor should not be mounted on glass bead •  Extension has to be used if operator must be mounted higher up on the wall * Min.
  • Page 8 Wall mounted operator, arm system PUSH •  Cut out the appropriate template from the card board box •  Ensure that the template aligns with the drawn line (X) and the L1. •  Use the stickers in the mounting kit to fix the template to the wall • ...
  • Page 9 Wall mounted operator, arm system PUSH 1. Drill the four mounting holes and the two holes for the door fitting. 2. Remove the template. 3. Tap, plug, or reinforce with rivnuts and screw the drive unit tight.
  • Page 10 Mounting the PUSH drive arm 1. Remove the door fitting from the arm system. 1. Adaptor 2. Drive arm 2. Screw the door fitting to the door leaf tight. 3. Mount the drive arm and adaptor on the operator drive shaft at an angle of 90°...
  • Page 11 Adjusting the PUSH arm system 1. Open the door and connect the door fitting with the drive arm (do not tighten the lock screws). 1. Telescopic part 2. Close the door and keep it closed. 2. Drive arm 3. Turn the drive arm until the telescopic part is at an angle of 90°...
  • Page 12 Wall mounted operator and arm system PULL Changing the direction of rotation 1. Mount the washer with the screw in the drive shaft, one from each side. 2. Dismantle the screws (4 pcs) from the bearing sleeves on both sides. 3.
  • Page 13 Wall mounted operator, arm system PULL •  Decide Z •  Draw a line on the wall for the underside of the mounting plate Note! •  D oor adaptor should be mounted aligned with upper edge of the door •  E xtension has to be used if operator must be mounted higher up on the wall...
  • Page 14 Wall mounted operator, arm system PULL •  Cut out the appropriate template from the card board box •  Ensure that the template aligns with the drawn line (Z) and the L1. •  Use the stickers in the mounting kit to fix the template to the wall • ...
  • Page 15 Wall mounted operator, arm system PULL 1. Drill the four mounting holes and the two holes for the door fitting. 2. Remove the template. 3. Tap, plug, or reinforce with rivnuts and screw the drive unit tight.
  • Page 16 Mounting the PULL door fitting 1. Tap, plug, or reinforce with rivnuts and 1. Door fitting screw the door fitting tight. 2. Door stop 3. Butt hinge...
  • Page 17 Mounting the PULL drive arm 1. Connect the mains power 2. Open the door to an angle of 90° 3. Give constant impulse by strapping the impulse inputs on the control unit. The operator drive shaft turns to a factory set position.
  • Page 18 Cont. Mounting the PULL drive arm 4. Slide the guide shoe into the door fitting. 5. Mount the drive arm on the operator drive shaft with the door in unchanged position 90°. Ensure that the teeth of the adaptor fit well with the operator. 6.

  • Page 19: Control Units

    Control units CSDA CSDA-S This basic control unit is equipped This slave control unit is used with inputs for connection of together with CSDA for double automatic and manual activation doors. units.
  • Page 20 Control units CSDA-F This extension unit is mounted on This unit is used if there are top of the CSDA to increase the requirements for extended functions CSDA functions . when the operator is used on fire doors or for connection of 24 V AC.
  • Page 21 Connection of control unit CSDA – single doors...
  • Page 22 Connection of TB1, TB2 and TB8...
  • Page 23 Connection of control units CSDA and CSDA-S – double doors...
  • Page 24 Connection of extension unit EXA – option...
  • Page 25 EXA extension unit Connection of TB9, TB10 and TB11...
  • Page 26 Adjustment HSO= High speed opening valve LSO= Low speed opening valve HSC= High speed closing valve LSC= Low speed closing valve LK=”Lock kick” screw Adjustment screw for spring force Adjustment screw for pump pressure 3.  Limit switch for adjustment of opening angle 4. ...
  • Page 27 Start-Up Give a short opening impulse by strapping the impulse input and adjust if necessary as follows. 1. Set the hold open time with the potentiometer on the control unit CSDA, 0-30 s. 2. Adjustment of the opening speed. a) Adapt the high speed opening HSO to the existing traffic situation. Turning clockwise decreases the speed.
  • Page 28 Cont. Start-Up 3. Adjustment of the closing speed. a) Adjust the low speed closing LSC as low as the traffic situation allows. Turning clockwise decreases the speed. b) Open the high speed closing valve, HSC (closed from factory) if a higher closing speed is required.
  • Page 29 Cont. Start-Up 5. Fine-adjust the opening angle by means of the limit switch. Unlock the lock screw. By moving the limit switch closer to the motor the opening angle is reduced. Note! To make the adjustment easier, the limit switch can be moved to the underside of the hydraulic unit.

  • Page 30: Closing Torque

    Closing torque To comply with authority requirements or to overcome over/under pressure the closing torque can be adjusted. The closing torque (spring force) is adjusted by means of an Allen screw placed at the end of the spring tube. The end plate has to be dismantled.

  • Page 31: Opening Torque

    Opening torque 1. If the closing torque (spring force) has been changed, or if the door does not open to its full extent, the opening torque (pump pressure) must be adjusted as follows: 2. The factory set torque for PUSH/SAS is 70 Nm and for PULL 40 Nm at an door opening angle of 0-2°.
  • Page 32 Connection of activation units and accessories...
  • Page 33 Fitting the standard cover Earth/Fastening screw Toothed washer for earth connection End plate Besam logotype...
  • Page 34 Fitting the double door cover 1. Dismantle cover end plates 2. Assemble the cover kit for double doors as shown...
  • Page 35 Fitting the special cover 1. Dismantle cover end plate 2. Assemble the cover kit for special cover as shown...

  • Page 36: Installation Examples

    Installation examples A. Steel reinforcement or rivnut B. Steel reinforcement C. Expansion-shell bolt min. M6x85 D. Wood reinforcement E. Steel beam...
  • Page 37 Accessories Cover – of clear anodized or paint finished aluminium. Programme selector – PSK-2, PSW-2, PS-4C and PS-3A. Activation units – see separate installation instructions. Extension unit, EXA- to be used if additional functions are required e.g. presence impulse, presence detection, Push and Go. Control unit, CSDA-F –...
  • Page 38 Cont. Accessories Shaft extension SEK – including bearing for extension 70-420 mm (2-3/4” – 16-17/32”). Coordination unit COOA – guarantees a safe and correct closing of rebated doors. Limit switch – to be used in combination with EXA to obtain Push & Go or mat safety.
  • Page 39 The New Besam Swing door operator PowerSwing...
  • Page 40 Door leaf-mounted operator, arm system SAS-F-5 •  Cut out the appropriate template from the card board box and turn it upside down. •  Decide X (2-17 mm) and move the template max. 180 mm away from the line L1. •  Make sure that the operator will not hit the wall when the door is open 90°. • ...
  • Page 41 Door leaf-mounted operator, arm system SAS-F-5 1. Drill the four mounting holes and the two holes for the door fitting. 2. Remove the template. 3. Tap, plug, or reinforce with rivnuts and screw the drive unit tight.
  • Page 42 Door leaf-mounted operator •  Mount the connection box on the wall. •  Mount the flexible hose and do the wiring.
  • Page 43 The New Besam Swing door operator PowerSwing...
