- Page 1 Operating instructions Vibratory bowl feeder SRC-N 63-2 SRC-N 100-2 Rhein-Nadel Automation GmbH...
- Page 2 Technical data Seite 3 Safety instructions Seite 3 Construction and function of the vibratory bowl feeder Seite 5 Transport and mounting Seite 6 Starting/Adjustment Seite 6 Maintenance Seite 8 Stockkeeping of spare parts and after-sales service Seite 8 What to do, if..? Seite 8 Instructions for trouble-shooting Declaration of conformity...
-
Page 3: Technical Data
Notice All vibratory bowl feeders listed in the table may only be operated in connection with a RNA control unit at a mains voltage of 230V/50Hz. Special voltages and frequencies see separate data sheet. 1 Technical data Vibratory bowl feeder type... - Page 4 Attention This warning triangle marks the safety instructions. Non-observance of these warnings can result in seri- ous or fatal injuries! Dangers occuring at the machine The most dangerous parts of the machine are the electrical installations of the vibratory bowl feeder. In case the vibratory bowl feeder becomes very wet, there is the danger of an electric shock! ...
- Page 5 Attention: Since the electromaget-field may have an impact on persons arrying pacemakers it is recommended to keep a minimum distance of 25 cm. Noise emission The noise level at the place of operation depends on the total equipment and the material to be sorted. The determination of the noise level according to the EC-Regulations "Machinery"...
- Page 6 A vibratory bowl feeder is a resonant system (spring-mass-system). The result is that the adjustment made at the plant will rarely meet your requirements. Chapter 5 shows how your vibratory bowl feeder is adapted to your requirements. As accessory parts we are offering a spectrum of sorting bowls, which cover a wide range of application. For special applications individual problem solutions can be manufactured.
- Page 7 the available supply voltage (frequency, voltage, power delivery) corresponds to the connecting data of the control unit (see type plate at the control unit). Plug in the mains cable of the control unit. Switch on the control unit with the mains switch. Notice At vibratory bowl feeders which are delivered as a completely adjusted system, the optimal conveying capacity is already set in the factory.
-
Page 8: Maintenance
6 Maintenance The vibratory bowl feeders are generally maintenance-free. They should only be thoroughly cleaned when they are considerably dirty or after fluids have been spilled over them. 7 Stockkeeping of spare parts and after-sales service The range of the spare parts available may be taken from the separate spare parts list. In order to guarantee a quick and faultless handling of the order, please state the following data at each indi- vidual order: ... - Page 9 ® Rhein-Nadel Automation GmbH Reichsweg 19/23 D - 52068 Aachen Tel (+49) 0241/5109-159 Fax +(49) 0241/5109-219 Internet www.rna.de Email vertrieb@rna.de Rhein-Nadel Automation GmbH Zweigbetrieb Lüdenscheid Nottebohmstraße 57 D - 58511 Lüdenscheid Tel (+49) 02351/41744 Fax (+49) 02351/45582 Email werk.luedenscheid@rna.de...
